Duplex LC / UPC Fiber Optic Connector Blue Color Singlemode OTOP Band​

♦ Optical fiber connector

- Insertion Loss: Single mode ≤ 0.2dB & Multimode ≤ 0.3dB
- Return Loss: PC ≥ 50dB, UPC ≥ 55dB & APC ≥ 65dB
- Durablity <0.2dB typical change, 1000 mating
- Operating Temperature: -40 to 80°C
- Ferrule Hole Sizes;

1) Superior qualified standard polishing;

2) 100% optic test: Insertion Loss: ≤0.3 (PC); ≤0.2 (APC); ≤0.2 (UPC); ≤0.3 (SPC);

3) 100% optic test: Return Loss: ≥45 (PC); ≥60 (APC); ≥55 (UPC); ≥50 (SPC);

4) φ0.9mm, φ2.0mm, φ3.0mm cable optional

5) Simplex and duplex connector available;

6) Good exchange ability and good durability;

7) Available in fiber bunch, ribbon fan-out, pigtail available;

8) Meets ISO9001, ROHS and Bell core GR 326-core standards;

9) Customized specifications are welcomed.

♦ Singlemode:

- 125.0+1/-0um, concentricity ≤ 1.0um
- 125.5+1/-0um, concentricity ≤ 1.0um
- 126.0+1/-0um, concentricity ≤ 1.0um

♦ Multimode:

- 125um concentricity ≤ 3um
- 127um concentricity ≤ 3um
- 128um concentricity ≤ 3um

♦ Availablity:

-The connector can be supplied as a pre-assembled one piece connector or as connector kits and one piece.
-Clips are available for FC and LC duplex connectors
-PC and APC are available
-Boots in a variety of colors

♦ Characteristic

1. With our own R&D, more completed production lines, advanced production & testing equipments, experienced staffs, we’re confident to provide you satisfied quality and service with competitive price and punctual delivery.

2. Rich experiences in OEM&ODM, besides standard items, we can help you design unique new products and put into production. We care about innovation and would like to change for you and grow up with you.

3. Prompt answer for any question or inquiry within 24 hours

4. Using ERP Systerm to ensure that each link is correct.

♦ Packing

- Carton
