SS Mini Tube Fiber Optic Plc Splitter For Fiber To The Point / Fiber To The Home
SS Mini Tube Fiber Optic Plc Splitter For Fiber To The Point / Fiber To The Home
Specifications
Brand Name :
ZGT
Model Number :
ZGT--SP-002
Certification :
ROHS,REACH ,IEC,GR326
Place of Origin :
CHINA
MOQ :
100PCS
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
900K PER MONTH
Delivery Time :
3-5days
Packaging Details :
Plastic bag
Product name :
sc upc apc gpon fiber optic plc splitter with manufacture price
Type :
Single Mode,1*2/1*4/1*8/1*16/1*32/1*64,Mini 2x8 plc optical splitter
Application :
FTTH FTTB FTTX PON CATV
Fiber type :
G.657A with 0.9mm lose tube,Single Mode,G657,0.9mm/2.0mm
Operating temperature :
-40℃ ~ 85 ℃
Connector type :
SC/APC,LC,FC,SC
Material :
PVC;ABS
Directivity :
≥55dB
Return loss :
55/50(DB)
Connector :
SC/UPC,no connector,SC/LC/FC/ST
Wavelength :
1260-1650nm,1310nm/1550nm
Insertion loss :
7.0dB,≤17.4dB
Warranty :
3 years
Fiber length :
≥1.0m,≥2m,1m,Customized
Size :
320 x 210 x85mm,130*100*25mm
Dimension :
60*12*4mm,12*8*1.8cm
Wide operating temperature :
-40°C - 85°C
Operator temperature :
-40~+85℃
Item :
high quality plc splitters fiber spliter
Description

fiber optic stainless steel mini-tube PLC splitter single mode ,multi mode,customized length

Serial Number: PLC mini module

Applications:

Fiber to The Point (FTTX)
Fiber to The Home (FTTH)
Passive optical networks(PON)
Local Area Networks (LAN)
Cable Television (CATV)
Test Equipment

Specifications:

Type 1×2 1×4 1×8 1×16 1×32 1×64 2×2 2×4 2×8 2×16 2×32 2×64
Fiber Type 9/125 um or customer appointed
Operating Wavelength(nm) 1260~1650
Insertion Loss(dB) Typical 3.6 6.8 10.0 13.0 16.0 19.5 4.0 7.0 10.5 13.5 16.5 20.5
(P/S)Max 3.8/
4.0		 7.1/
7.3		 10.2/
10.5		 13.5/
13.7		 16.5/
16.8		 20.5/
21.0		 4.1/
4.3		 7.4/
7.6		 10.8/
11.0		 14.3/
14.5		 17.3/
17.5		 20.7/
21.5
Loss Uniformity(dB)-Max 0.6 0.6 0.8 1.2 1.5 2.5 0.8 0.8 1.5 2.0 2.5 2.5

Polariation

Dependent Loss(dB)-Max

 0.15 0.15 0.25 0.3 0.3 0.3 0.2 0.2 0.3 0.4 0.4 0.4

Dimension(WxHxL)(mm)

Ribbon/Bare Fiber

 4×4
×40		 4×4
×40		 4×4
×40		 4x7
x50		 4x7
x50		 4x12
x60		 4×4
×50		 4×4
×50		 4×4
×50		 4x7
x60		 4x7
x60		 4x12
x60

Dimension(WxHxL)(mm)

ABS BOX(0.9, 2.0, 3.0mm)

 100x
80x10		 120x80x18 141x114x18 100x80x10 120x80x18 141x114x18
Directivity(dB)-Min 55
Return Loss(dB)-Min UPC:50 APC:60
Operating Temperature(℃) -40~85
Storage Temperature(℃) -40~85
Connector type FC, SC.ST, LC, MU…..

1. Measured at room temperature and excludes connector loss.
2. For devices with connectors, insertion loss will be 0.3dB higher.
