Fiber optic adapter SC to LC hybrid adapter with metal housing long flange APC/UPC/SM/MM,LOW LOSS
Fiber optic adapter SC to LC hybrid adapter with metal housing long flange APC/UPC/SM/MM,LOW LOSS
Fiber optic adapter SC to LC hybrid adapter with metal housing long flange APC/UPC/SM/MM,LOW LOSS
Fiber optic adapter SC to LC hybrid adapter with metal housing long flange APC/UPC/SM/MM,LOW LOSS
Specifications
Brand Name :
ZGT
Model Number :
ZZTAD-SCLC-S-M
Certification :
ROHS,REACH ,IEC,GR326
Place of Origin :
CHINA
MOQ :
100PCS
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
900K PER MONTH
Delivery Time :
3-5days
Packaging Details :
Plastic bag
Description

Hybrid adaptorYou are here: Home > Products > Fiber Optic Adapter

SC to LC hybrid adapter with metal housing

Fiber optic adapter SC to LC hybrid adapter with metal housing long flange APC/UPC/SM/MM,LOW LOSS

Serial Number: ZZTAD-SCLC-S-M

Competitive Advantage:

Telcordia GR-326, IEC, TIA/EIA Standard compliant.

100% Optical performance inspection.

Low Insertion Loss.

RoHS Compliance.

Customized design and production.

Parts &Material

Parts

Material

Remarks

Sleeve

Ceramic/ NIckel

Housing

Zinc alloy/Copper

Dust cap

PE

Flammability UL94 V-0

Optical Performance

Premium Grade

Standard Grade

Insertion Loss

≤0.1dB

≤0.2dB

Durability

1000 times

1000 times

Enviroment and Mechanical

Properties

Test condition

Conformance

Test result

Vibration

10-55Hz, 1.5mm, 60min

IEC61300-2-1

≤0.2dB

Mating Durability

1000 Mating, clean every 25 mating.

IEC61300-2-2

≤0.2dB

Impact

1.5m, 8 drops

IEC61300-2-6

≤0.2dB

Strength of Coupling Mechanism

40N, 10Min, L=22-28cm

IEC61300-2-12

≤0.2dB

Temperature Cycling

40C to +75C, 40 cycles

IEC61300-2-22

≤0.2dB

Temperature humidty cycling
