Specifications
Brand Name :
ZGT
Model Number :
ZGT-FT-005
Certification :
CE/ROHS/ISO9001,ISO9001,CE
Place of Origin :
CHINA
MOQ :
N/A
Price :
NEGOTIALABLE
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1000000
Delivery Time :
3-5DAYS
Packaging Details :
PE BAG
Name :
Outdoor Cable Assembly
Connector :
SC
Insertion loss :
≤0.3dB(max)
Temperature :
-40℃ -- +70℃
Type :
Coaxial,Unshielded,Cat 6a,Adapter
Description

SC APC fast connectors fiber optic quick connect fiber optic connectors

1. Description

Our SC fast connectors make fiber terminations quick, easy and reliable. These fiber optic connectors offer terminations without any hassles and require no epoxy, no polishing, no splicing, no heating and can achieve similar excellent transmission parameters as standard polishing and splicing technology. Our fast connector can greatly reduce the assembly and set up time. The pre-polished connectors are mainly applied to FTTH cable in FTTH projects, directly in the end user site.

2. Features

1.Factory-installed fiber stub

2.Low insertion loss

3.Quick and easy fiber termination in the field .

4.Eliminates cable excess length and pigtail splicestorage

5.Cost effective 6.Applicable to bow-type drop cable and 2.0/3.0 indoor cable ,telecom cable

3. Specification

product name
FTTH SC/APC fiber optic fast connector
Item
value
Insertion loss
≤0.3dB(Max.0.5)
Return loss
≥60dB
Connector type
SC
Fiber cable type
Drop cable:3mm,flat:2x3 mm cable,0.9/2.0/3.0 fiber cable

4. Application

Used to open the FTTH fiber terminal end.
In the box, cabinet, such as wiring into the box.
Off the back of the accidents such as fiber, maintenance.
LAN, wan, data and video transmission.
The construction of the fiber end user access and maintenance.
Optical fiber access of mobile base station.

No Splicing Fiber Cable Assembly Fast Field Connector SC/APC Low Loss Long Lifespan

No Splicing Fiber Cable Assembly Fast Field Connector SC/APC Low Loss Long Lifespan

5.Performance


(1).Insertion loss:≤0.3~0.5dB ,Return loss:≥60dB.
(2). Mechaincal Durability:1000matings
(3).Storage temperature:-40℃to+85℃
(4).Operation temperature:- 40 ~ + 85 ℃
(5).Tensile Strengh:>30N
(6).Number of repeated use:5 times above
(7).SC connector according to IEC 61754-4 .
(8).Suitable for cable outer diameter 0.9 mm, 2.0 mm and 3.0 mm, 2 * 3.0 mm.
