Fiber Optical SC FC ST Light Source Power Meter FTTH Tools
Fiber Optical SC FC ST Light Source Power Meter FTTH Tools
Fiber Optical SC FC ST Light Source Power Meter FTTH Tools
Fiber Optical SC FC ST Light Source Power Meter FTTH Tools
Fiber Optical SC FC ST Light Source Power Meter FTTH Tools
Fiber Optical SC FC ST Light Source Power Meter FTTH Tools
Specifications
Brand Name :
JW
Model Number :
JW3208
Place of Origin :
china
MOQ :
1set
Price :
By negotiation
Payment Terms :
L/C, T/T
Supply Ability :
Up to different machine
Delivery Time :
Min.30working days
Packaging Details :
Plastic film+wooden box
Use :
FTTH
Product name :
optical light source
Operating Temperature :
-10 -- +50℃ , < 90%RH
alibrated Wavelengths(nm) :
850/980/1300/1310/1490/1550
Power Supply :
3 pcs1.5V AA batteries
Optical Connector :
FC,SC,ST
Description

FTTH Tools Fiber Optical SC FC ST Light Source Power Meter

1. Description of FTTH Tools Fiber Optical SC FC ST Light Source Power Meter

  • JW3208 handheld optical power meter is a compact and an easy-to-use testing instrument for optical fiber networks, which can be used for absolute optical power measurements. It features ingenious appearance, wide range of power measurement, high accuracy and user self-calibration function with high performance-to-price ratio.

2. Technical of FTTH Tools Fiber Optical SC FC ST Light Source Power Meter

Type

JW3208A

JW3208C

Wavelength(nm)

800~1700nm

Detector

InGaAs

Measurement Range (dBm)

-70~+6

-50~+26

Uncertainty

±5%

Calibrated Wavelength(nm)

850,980,1300,1310,1490,1550

Resolution(dB)

0.01

Optical Connector

FC(interchangeable SC,ST) / as well as 2.5mm universal

Power Supply

Alkaline Battery(3 AA 1.5V batteries)

Battery Operating Time

240 h with 1.5V Battery(3)

Operating Temperature(°C)

-10 ~ +60

Storage Temperature(°C)

-25 ~ +70

Relative Humidity

0 to 95% (non-condensing)

Dimension(mm)

175x82x33

Weight(g)

310

3. Features of FTTH Tools Fiber Optical SC FC ST Light Source Power Meter

  • Self calibration by user himself

  • Rechargeable lithium battery supports continuous work for up to 48 hours.

  • Linear indicators (mW) and non-linear indicators (dBm) display in one screen

  • UniqueFC/SC/ST universal port (see Figures 1, 2), no complex conversion VFL function

  • 4-digit LCD display, supporting three display formats: dB,nw and dBm

  • Automatic range switching

  • Automatic power-off, BacklightON/OFF

  • Multi-wavelength measurement

  • Low power indication
