Specifications
Model Number :
DWDM
Place of Origin :
China
Brand Name :
ODM/OEM
Packaging Details :
Plastic box
Carton box
Or as customers requirements
Supply Ability :
10000 Set/Sets per Day
MOQ :
2 pieces
Price :
$50.00 - $150.00/pieces
Certification :
RoHS, CE
Payment Terms :
T/T, Western Union
Type :
DWDM Module, ABS box module
Use :
FTTX
Channel Number :
4CH, 8CH or 16CH
Structure :
Mux or Demux
Channel Spacing :
100G(0.8nm)
Channel Wavelength :
ITU 100 GHz Grid
Input/Output connector :
FC, SC, LC optional
Input/Output length :
0.5m, 1m or customized
Pigtail Diameter :
0.9mm
Package dimension :
100X80X10mm
Application :
Telecommunication
Description
Product Description
8 16 18 channel WDM CWDM DWDM Mux Demux Module, 4CH fwdm cwdm mux 1310/1490/1550 FWDM cwdm mux demux
DWDM multi-channel multiplexer /demultiplexer (Mux /DeMux)modules are available on ITU channel spacing of 200GHz. They demonstrate low loss, temperature insensitivity and reliable performance in any system application.Mux/DeMux modules offer low-cost wavelength management solutions that are suitable for long haul, metro, and access application.
WDM CWDM Dwdm Mux Demux Module 16 Channel 18 Channel For Telecommunication
WDM CWDM Dwdm Mux Demux Module 16 Channel 18 Channel For Telecommunication
WDM CWDM Dwdm Mux Demux Module 16 Channel 18 Channel For Telecommunication
WDM CWDM Dwdm Mux Demux Module 16 Channel 18 Channel For Telecommunication
WDM CWDM Dwdm Mux Demux Module 16 Channel 18 Channel For Telecommunication
Parameter
4-Channel
8-Channel
16-Channel
Mux
Demux
Mux
Demux
Mux
Demux
Channel Wavelength(nm)
ITU 100GHz Grid
Channel Spacing(GHz)
100(0.8nm)
Channel Passband (@-0.5dB bandwidth(nm)
>0.25
Insertion Loss(dB)
≤1.8
≤3.7
≤5.5
Channel Uniformity(dB)
≤0.6
≤1.0
≤1.5
Channel Ripple(dB)
<0.3
Isolation(dB)
Adjacent
N/A
>30
N/A
>30
N/A
>30
Non-adjacent
N/A
>40
N/A
>40
N/A
>40
Insertion Loss Temperature Sensitivity(dB/℃)
<0.005
Wavelength Temperature Shifting (nm/℃)
<0.002
Polarization Dependent Loss(dB)
<0.1
<0.1
<0.15
Polarization Mode Dispersion(ps)
<0.1
Directivity(dB)
≥50
Return Loss(dB)
≥45
Maximum Power Handling(mW)
300
Opterating Temperature(℃)
-5~+75
Storage Temperature (℃)
-40~+85
Package dimension(mm)
A: L100×W80×H10
B: L120×W80×H18
C: L141×W115×H18
WDM CWDM Dwdm Mux Demux Module 16 Channel 18 Channel For Telecommunication
WDM CWDM Dwdm Mux Demux Module 16 Channel 18 Channel For Telecommunication
Main Products
WDM CWDM Dwdm Mux Demux Module 16 Channel 18 Channel For Telecommunication
Our Company
We are a leading company in developing and manufacturing advanced fiber optic products,mainly make fiber optic indoor and outdoor cable, CPRI waterproof jumper, MPO/MTP jumper , standard fiber optic jumper and PLC Splitter. With years of experiences in the fiber optic industry, our factory is fully equipped over 5000 square meters and more than 30 non dust production lines .About 250 well-trained staff and engineers are contributing to our proud products. We have 5 production lines for fiber optic cable, 2 high standard MPO/MTP jumper assembly lines, 15 production lines for standard jumper and 8 PLC Splitter production lines. The most advanced imported polishing equipment and testing instruments enable our products have super quality, such as Senko polishing machine, interferometer, automatic cleaning machine and OTDR ,JGR and so on. All of our optical products are RoHS compliant and also obtained ISO9001, ISO14001 certification. Our high quality products and outstanding service win the customer from all the world, Our fiber optic is looking forward to cooperate with you.
