LC ST Patch Cord For Telecom System , Duplex Fiber Optic Cable 2M 3M 5M 15M
LC ST Patch Cord For Telecom System , Duplex Fiber Optic Cable 2M 3M 5M 15M
LC ST Patch Cord For Telecom System , Duplex Fiber Optic Cable 2M 3M 5M 15M
LC ST Patch Cord For Telecom System , Duplex Fiber Optic Cable 2M 3M 5M 15M
LC ST Patch Cord For Telecom System , Duplex Fiber Optic Cable 2M 3M 5M 15M
LC ST Patch Cord For Telecom System , Duplex Fiber Optic Cable 2M 3M 5M 15M
LC ST Patch Cord For Telecom System , Duplex Fiber Optic Cable 2M 3M 5M 15M
LC ST Patch Cord For Telecom System , Duplex Fiber Optic Cable 2M 3M 5M 15M
Specifications
Brand Name :
ANSHI
Model Number :
AS-ODF--SC/ST
Certification :
ISO9001
Place of Origin :
China
MOQ :
CAN DISCUSS
Price :
Negotiable
Supply Ability :
100000 pcs per month
name :
fiber optic jump cable
Return loss :
≥50.00dB(PC) ≥65.00dB(APC)
Connector Type :
SC/FC/LC/ST/MU/MTRJ
Length :
1m,2m,3m...
Cable Type :
Simplex/Duplex
Fiber Type :
SM/MM
Tensile Strength :
≥10KGS
Repeatability :
≤0.1
Insertion loss :
0.3dB
fiber :
corning
Description

LC/PC-ST/PC Duplex jump cable fiber optic patch cord 2M, 3M, 5M, 15M Can be customized

Features

IEC61754-7 Compliant;Telcordia GR-1435-CORE compliant
Push -Pull locking type
Ferrules are available for SM Standard,SM LowLoss
MM Standard,MM LowLoss
Cable are available for Jacket ribbon,Bare ribbon
Round mini Cable
High Return Loss;Low Insertion Loss
High precision guide pins for exact alignment

Application

* Telecom system

* Cabling system

* High Density optical laser

* QSFP devices

Model NO.

 LC-ST fiber optic patch cord
Style LC,SC,ST,FC.MU,MPO, SC/APC,FC/APC,LC/APC.MU/APC Duplex MTRJ/Female, MTRJ/Male
Fiber Type

9/125 SMF-28 or equivalent (Singlemode) OS1&OS2 50/125, 62.5/125 (Multimode) OM4,OM3,OM2,OM1 50/125,

10G (Multimode) OM3
Cable Type

Simplex, Duplex (Zipcord) Φ3.0mm, Φ2.0mm, Φ1.8mm Φ1.6mm PVC or LSZH Φ0.9mm, Φ0.6mm buffered fiber

PVC or LSZH
Polishing Manner UPC,SPC,APC (8°& 6°)
Insertion Loss ≤ 0.1dB (For Singlemode Master) ≤ 0.25dB (For Singlemode Standard) ≤ 0.25dB (For Multimode) Tested by JDS RM 3750
Return Loss (For Singlemode)

UPC ≥ 50dB SPC ≥ 55dB APC ≥ 60dB (typ.65dB)

Tested by JDS RM3750
Repeatability ±0.1dB
Operating Temperature -40C to 85C
Geometry Requirement (For Singlemode) Ferrule Endface Radius 7mm ≤ R ≤ 12mm (For APC) 10mm ≤ R ≤ 25mm (For Standard) Apex Offset ≤ 30 μm (For Master) Apex Offset ≤ 50 μm (For Standard) Undercut -50nm ≤ U ≤ 50nm Tested by DORC ZX-1

LC ST Patch Cord For Telecom System , Duplex Fiber Optic Cable 2M 3M 5M 15M

LC ST Patch Cord For Telecom System , Duplex Fiber Optic Cable 2M 3M 5M 15M
