AS-OLT-03A GPON OLT Supports 1 /128 Split Ratio Access 2048 ONU Users At The Same Time
AS-OLT-03A GPON OLT Supports 1 /128 Split Ratio Access 2048 ONU Users At The Same Time
AS-OLT-03A GPON OLT Supports 1 /128 Split Ratio Access 2048 ONU Users At The Same Time
AS-OLT-03A GPON OLT Supports 1 /128 Split Ratio Access 2048 ONU Users At The Same Time
Specifications
Brand Name :
ANSHI
Model Number :
AS-OLT-03A
Certification :
ISO9001, SGS
Place of Origin :
ZHEJIANG, CHINA
MOQ :
Negotiable
Price :
Negotiable
Product name :
GPON OLT
GPON interface :
16 x GPON (1.25/2.5 Gbps)
10GE Ethernet :
4 x RJ-45
Dimensions :
440mmX400mmX44mm
Weight :
＜ 6.5KG
Spaging ratio :
1: 128
Description

AS-OLT-03A GPON OLT Supports 1:128 split ratio,can access 2048 ONU users at the same time

Product Overview

AS-OLT-03A is GPON OLT series product, 19-inch 1U height rack-mounted, featuring small size, convenience and flflexibility, easy deployment, and high performance. Easy installation and maintenance,saving space.
AS-OLT-03A GPON OLT provides 16 standard EPON PON ports ; 4 uplink GE Ethernet RJ45 ports; 4*10GE SFP+ optical ports.Supports 1:128 split ratio,can access 2048 ONU users at the same time. Support difffferent types of ONU hybrid networking, suitable for triple play,Video network, corporate LAN, and Internet of Things scenarios. Provide perfect, intelligent, powerful, advanced and professional solutions for FTTH/FTTB/FTTO projects.

Product Specifications
GPON interface
16 x GPON (1.25/2.5 Gbps)
10GE Ethernet
4 x 10GE SFP+
1GE Ethernet
4 x RJ-45
GPON
ITU-TG.984.x standard
Console
RJ-45 EIA/TIA-232 Console management port
MGMT
1000BASE-T out-band management port
Switching Capacity
148Gbps
Spaging ratio
1: 128
Maximum ONU quantity
4096 GEM port-ids, 1024 T-CONT, 128 ONT
Power Adaptor
AC Input::100 to 240 V AC, 50/60 Hz; DC Input : 36V-75V(optional)
Redundancy Design
Pluggable double power supply, double AC, double DC and AC+DC
Consumption
＜84 W
Storage
temperature -10 to 70°C, rel. humidity 10‒90% (non-condensing)
Operation
temperature 0 to 45°C, rel. humidity 10‒90% (non-condensing)
Dimensions
440mm×400mm× 44mm(W * D *H)
Weight
＜ 6.5KG
