Specifications
Brand Name :
E-link
Model Number :
ETH-DIMC2416MP
Certification :
ISO9001, CE, RoHS, FCC
Place of Origin :
China
MOQ :
1PCS
Price :
Negotiation
Payment Terms :
Paypal, TT, Western Union, MoneyGram, Alipay
Supply Ability :
5000pcs per month
Delivery Time :
3~5 working days
Packaging Details :
Industrial Ethernet POE Switch Standard Export Package
Product Name :
Industrial Ethernet POE Switch
Dimensions :
155 x 115 x 85 mm
Optical Port :
4 x 1000Base-X SFP
Connector :
16 x RJ45
Input Power :
48~57VDC
Storage Temperature :
-40°C to 85°C (-40°F to 185°F)
Description

Industrial Ethernet PoE Switch's Product Description:

ETH-DIMC2416MP Series is the L2+ managed 16-port 10/100/1000Base-T 802.3at PoE + 4-port 1000Base-X SFP hardened Ethernet switch. This Industrial Ethernet Switch has 16 TP ports and 4 fiber ports. The TP (RJ45) supports 10/100/1000Base-T(X), Full/Half duplex mode, and auto MDI/MDI-X connection; the 1000Base-X SFP port supports 1 or 2 core Single-mode or Multi-mode fiber. With its reliable design and ease of use, this Industrial Ethernet Switch is a great choice for integrating networks consisting of network devices such as IP cameras and wireless access points between remote locations.

Industrial L2+ 16-Port 10/100/1000T 802.3at PoE plus 4-Port 1000X SFP Managed Ethernet Switch

Industrial Ethernet PoE Switch's Features:

► Support 16x10/100/1000Base-T + 4x1000Base-X SFP +

► 10/100/1000Mbps RJ45 Port supports Full/Half-duplex, Auto-negotiation, Auto MDI/MDIX

► IEEE802.3af/at compliant

► DIP Switch supports one-key VLAN, one-key Ring Management, PoE Reset and 250m PoE Network

► Support connecting USB-C port for easy management, without the need to access the RS232 serial port at all

► 10K Bytes Jumbo Frame

► IEEE 802.3az Energy Efficient Ethernet (EEE)

► IP40 Aluminum Case

► Supports DIN-Rail installation

► -40°C to 80°C (-40°F to 176°F) operating temperature

Industrial Ethernet PoE Switch's Technical Parameters:

Standards: IEEE802.3 10BASE-T
IEEE802.3u 100BASE-TX/FX
IEEE802.3ab 1000BASE-T
IEEE802.3z 1000BASE-X
IEEE802.3p QoS
IEEE802.1d Spanning Tree
Forward & Filtering Rate: 14,880pps (10Mbps)
148,800pps (100Mbps)
1,488,000pps (1000Mbps)
Packet Buffer Memory: 12M bits
Processing Type: Store-and-Forward
Backplane bandwidth 110Gbps
Max Packet Length: 10K Bytes Jumbo Frame
RS485: 1 x RS485 (Optional)
Power Pin Assignment 4/5(+), 7/8(-)
PoE Budget: Up to 480-watt PoE budget
Relative Humidity: 5% to 95% non-condensing

Industrial Ethernet PoE Switch's Applications:

Industrial L2+ 16-Port 10/100/1000T 802.3at PoE plus 4-Port 1000X SFP Managed Ethernet Switch

Industrial Ethernet PoE Switch's Support and Services:

Industrial Ethernet PoE Switch technical support and services include:

  • 24/7 online technical support
  • Free installation services
  • Onsite technical support
  • Regular system updates and upgrades
  • Training and education

Industrial Ethernet PoE Switch's Packing and Shipping:

Industrial Ethernet PoE Switch is packaged for shipping in a strong, corrugated box designed to ensure safe transport and handling. The interior is filled with protective foam inserts to help cushion the product against shock and vibration, while the exterior of the box is clearly labeled with product and shipping information.

Industrial Ethernet PoE Switch's Ordering Information:

Model Description
ETH-DIMC2416MP Industrial L2+ 16-Port 10/100/1000T 802.3at PoE + 4-Port 1000X SFP Managed Ethernet Switch
SFP Options ► SFP option. Please select your SFP on our SFP Options Page
► SFP module is to be purchased separately.
Mounting Options ► Default DIN-Rail Bracket installed
Power Options ► DIN-Rail Power Supply. Open Wire for Terminal Block.
► Power Supply is to be purchased separately.
