Portable Mini Handheld 20W 25W 30W Fiber Laser Marking Machine Factory Directly Price Laser Marker Engraving for Sale
Portable Mini Handheld 20W 25W 30W Fiber Laser Marking Machine Factory Directly Price Laser Marker Engraving for Sale
Portable Mini Handheld 20W 25W 30W Fiber Laser Marking Machine Factory Directly Price Laser Marker Engraving for Sale
Portable Mini Handheld 20W 25W 30W Fiber Laser Marking Machine Factory Directly Price Laser Marker Engraving for Sale
Portable Mini Handheld 20W 25W 30W Fiber Laser Marking Machine Factory Directly Price Laser Marker Engraving for Sale
Portable Mini Handheld 20W 25W 30W Fiber Laser Marking Machine Factory Directly Price Laser Marker Engraving for Sale
Portable Mini Handheld 20W 25W 30W Fiber Laser Marking Machine Factory Directly Price Laser Marker Engraving for Sale
Portable Mini Handheld 20W 25W 30W Fiber Laser Marking Machine Factory Directly Price Laser Marker Engraving for Sale
Portable Mini Handheld 20W 25W 30W Fiber Laser Marking Machine Factory Directly Price Laser Marker Engraving for Sale
Portable Mini Handheld 20W 25W 30W Fiber Laser Marking Machine Factory Directly Price Laser Marker Engraving for Sale
Portable Mini Handheld 20W 25W 30W Fiber Laser Marking Machine Factory Directly Price Laser Marker Engraving for Sale
Portable Mini Handheld 20W 25W 30W Fiber Laser Marking Machine Factory Directly Price Laser Marker Engraving for Sale
Portable Mini Handheld 20W 25W 30W Fiber Laser Marking Machine Factory Directly Price Laser Marker Engraving for Sale
Portable Mini Handheld 20W 25W 30W Fiber Laser Marking Machine Factory Directly Price Laser Marker Engraving for Sale
Portable Mini Handheld 20W 25W 30W Fiber Laser Marking Machine Factory Directly Price Laser Marker Engraving for Sale
Portable Mini Handheld 20W 25W 30W Fiber Laser Marking Machine Factory Directly Price Laser Marker Engraving for Sale
Portable Mini Handheld 20W 25W 30W Fiber Laser Marking Machine Factory Directly Price Laser Marker Engraving for Sale
Portable Mini Handheld 20W 25W 30W Fiber Laser Marking Machine Factory Directly Price Laser Marker Engraving for Sale
Specifications
Brand Name :
KEYILASER
Model Number :
KY-M-FB20/25/30
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
500set/month
Delivery Time :
7-10days
Packaging Details :
wooden package
Working Accuracy :
0.01mm
Graphic Format Supported :
AI, BMP, Dst, Dwg, DXF, DXP, LAS, PLT
Cooling Mode :
Air Cooling
Weight :
7.8kg
Marking Area :
100*100mm
Feature :
Handheld Mobile
Focal length :
160mm (limited)
Fiber Length :
1.8m
Pulse Width :
90±10ns
Maximum single pulse energy :
0.7mJ
Beam quality :
M2<1.5
Machine size (L*W*H) :
280mm*210mm*330mm
Description

Portable Mini Handheld 20W 25W 30W Fiber Laser Marking Machine Factory Directly Price Laser Marker Engraving for Sale

Product Description

Portable Mini Handheld 20W 25W 30W Fiber Laser Marking Machine Factory Directly Price Laser Marker Engraving for Sale

Unmatched precision and usability are offered by this state-of-the-art, multifunctional portable compact mobile laser marking equipment.
Because of its compact size and light weight, it can be used in a range of settings, such as offices, industries, and hospitals.

This equipment consistently yields the best results when it comes to marking serial numbers, logos, and barcodes. With its powerful technology and intuitive interface, it's an essential tool for any business or individual looking to improve their mark.

So why hold off? Invest as soon as possible in a small, light, and portable laser marking machine to boost production!

Portable Mini Handheld 20W 25W 30W Fiber Laser Marking Machine Factory Directly Price Laser Marker Engraving for Sale

Laser marking is a new technique that uses a substance's interaction with a laser to leave a visible mark on an object's surface.

Hand-held laser marking can be more advantageous than traditional marking techniques because of its accuracy, lack of substrate damage, "green" environmental protection, online availability, and adaptability for high-speed online marking in specific regions.

Portable Mini Handheld 20W 25W 30W Fiber Laser Marking Machine Factory Directly Price Laser Marker Engraving for Sale

Equipment Features
○ Accurate and efficient marking that doesn't harm the part matrix;
○ Precise marking that allows for the selective marking of exact size and position.
○ It is safe and environmentally friendly; no consumables are required.
○ Handheld, portable, and simple to use marking.
○ Because of its ergonomic design, operation requires significantly less labor intensity; excellent marking effectiveness and time savings; the laser marking system is reliable and needs very little upkeep.
○A transportable battery module is optional.
Portable Mini Handheld 20W 25W 30W Fiber Laser Marking Machine Factory Directly Price Laser Marker Engraving for Sale

Product Implementation Standards

Our organization has established a quality assurance system for the design, manufacture, and maintenance of small and medium power laser processing equipment. We have also successfully attained ISO 9001 international accreditation for our quality management system.

The working environment and conditions, including basic technical requirements, cooling restrictions, safety from laser radiation, electrical safety, test techniques, inspection and acceptance, packaging, and transportation during the production process, are all outlined in the comprehensive standards that our firm has developed. The requirements are:

GB10320: Electrical Safety of Laser Equipment and Facilities
GB7247 Radiation Safety, Equipment Classification, Requirements and User Guide for Laser Products
GB2421: Basic environmental test procedures for electronic products
GB/TB360 Specification for Laser Power Energy Test Instrument
GB/13740 Test method for divergence angle of laser radiation (GBT13741) Test method for beam diameter of laser radiation GB/13862-92 Test method for laser radiation power
(GB2828-2829-87) Batch-by-batch periodic inspection and counting sampling procedure and sampling table
Specification
Power
20W/25W/30W
Machine power consumption
＜200W
working ambient temperature
-5℃～40℃
Humidity of working environment
≤80%
power instabilities
＞5%
Pulse Width
90±10ns
Maximum single-pulse energy
0.7mJ
Beam quality(M2)
＜1.5
Scanning Range (L*W)
100*100mm
Scan frequency
1-600kHz
Focal depth
About 2mm
Marking handle weight
＜0.9Kg

Portable Mini Handheld 20W 25W 30W Fiber Laser Marking Machine Factory Directly Price Laser Marker Engraving for Sale

Portable Mini Handheld 20W 25W 30W Fiber Laser Marking Machine Factory Directly Price Laser Marker Engraving for Sale

Operating Steps

Step 1: Take the handheld marking handle and remove the lens dust cover of the field lens of the lasermarking handle.

Step 2. Insert one end of the special power adapter into the power port of the handheld laser markingmachine, connect the power cord plug at the other end, and press the power button.

Step 3. After the system is started, complete the parameter setting of the laser marking file through the touch-screen interface.

Step 4. After setting the parameters of the laser marking file, put on the laser protective glasses, align thehandle with the workpiece to be processed, press the laser marking key on the handle with your finger todisplay the red light preview of the processing file, and press the laser marking key on the handle againAfter marking, you can also use the touch-screen interface of the control software to click to power on, preview with a red light, and output marking.
Step 5. After use, turn off the power button of the laser marking screen, cover the dust cover of the fieldlens, turn off the power button, and cut off the power supply ofthe special power adapter
Software Control Interface
Portable Mini Handheld 20W 25W 30W Fiber Laser Marking Machine Factory Directly Price Laser Marker Engraving for Sale
Machine Application
The compact, lightweight, mobile laser marking machine is a versatile tool with many applications. Thanks to its precise, high-quality markings, this small gadget makes it easy to identify items for identification or engrave personalized phrases on gifts.

This one is the best choice for assignments that require you to work remotely because of its compact design and wifi capabilities, which let you finish tasks while you're on the go and generate high-quality work wherever you are.

Choose the Handheld Mini Mobile Laser Marking Machine for your marking needs to experience the power and use of this amazing piece of equipment!

Portable Mini Handheld 20W 25W 30W Fiber Laser Marking Machine Factory Directly Price Laser Marker Engraving for Sale
FAQ
1) When will you be delivering?
After receiving the deposit, we will set up the delivery within three to seven working days.
2) Which methods of payment are accepted?
Payment options include credit card, PayPal, Western Union, T/T or LC, and more.
3) How can you assist us in resolving a technical issue, if I have one?
We can be reached via phone, video call, or email. Give us a thorough explanation of the issue, together with any supporting documentation in the form of images and videos, so that our professionals can assess it and offer appropriate fixes.
4) How can I decide which one is best for me?
Tell me your maximum working area, please. Select the model that best fits your needs.Select the power that works best for the thickness of the materials and products.
5) What should I do if this system has any issues?
We offer a one-year warranty on machines. If there is a problem with the machine during the one-year guarantee, we will replace the parts at no cost to you (except for intentional damage).
