Specifications
Brand Name :
Perfect Laser
Model Number :
PE-S70
Certification :
CE / ISO / FDA / SGS / TUV
Place of Origin :
China
MOQ :
1 Unit
Price :
Negotiable
Payment Terms :
T/T, L/C, PayPal, Western Union
Supply Ability :
500 Unit per Month
Delivery Time :
7-15 Working Days
Packaging Details :
Sea-Worthy Packing
Nozzle type :
Special design
Ink :
special designed for wall printing
Surface tracking :
Bi-curved BANNER sensor
Feeder system :
Automatic feed
Image type :
JPG、BMP、TIFF、PDF、AI、PSD、CDR
Power :
AC110V (90-132V) / AC220V (180—264V) Alternating current, 47-63HZ
Package type :
Compound wooden case comply with exporting standard
Payment :
T/T, L/C, PayPal, Western Union
Width :
670mm
Height :
2640mm
Description

High Precision USA Senor Piezoelectric Nozzle 3D Wall Mural Printer Machine

(Model: PE-S70)

※Product Production Of Wall Printer :

Perfect Laser's new intelligent 3d wall printer machine PE-S70 adopts a newly developed integrated control board, full wireless control system, touching screen, internal electronic library storage. You can put in files by inserting U disk directly without extra computer. The 3d wall printer machine is easy to install and operation.
The 3d wall printer machine uses the United States imported sensors, automatically sensing the distance between the wall; and equipped with Japan's imports of piezoelectric nozzle, wall mural printer machine is more accurate and faster. This digital wall printing is also equipped with a high-precision brushless servo motor control system, eliminating post-maintenance. The inkjet printer on wall is deeply loved by customers when it comes.

High Precision Wall Inkjet Printer USA Senor Piezoelectric Nozzle Automatic Feeder System

※Product Features Of Wall Printer

1. The main body of the Wall Mural Printer Machine on wall is assembled by specially formulated aluminum-magnesium alloys, which has higher strength and higher structural accuracy. Highly integrated and lightweight chassis, light weight and durable, easy to be carried.
2. The whole body of vertical wall printing machine is manufactured by advanced CNC equipment with professional mold parts manufacturing process, ensure the better consistency and higher stability of the whole 3d wall printer machine and accessories.
3. The Wall Mural Printer Machine adopts high precision brushless control system of servo motor, the vector orientation, no bar grating, no carbon brush motor are in order to achieve the 3d wall printer machine higher accuracy and faster speed of coloured drawing and free maintenance.
4. Automatically restart from break points after interruption, automatically remember break points, automatic cover the starting position. The inkjet printer on wall can automaticallycontinue to print from the break points. You can finish alarge workpiece during several days.
5. Vertical printer use Advanced AC servo control technology to ensure more high-precision printing, better stability and longer service life of the 3d wall printer machine.
High Precision Wall Inkjet Printer USA Senor Piezoelectric Nozzle Automatic Feeder System
High Precision Wall Inkjet Printer USA Senor Piezoelectric Nozzle Automatic Feeder System
High Precision Wall Inkjet Printer USA Senor Piezoelectric Nozzle Automatic Feeder System
High Precision Wall Inkjet Printer USA Senor Piezoelectric Nozzle Automatic Feeder System
※Application Of Wall Printer

The 3d wall printer machine is widely applied in interior and exterior wall putty wall, latex painted wall , white wall, Imitation porcelain walls, ceramic tiles, glass, rice paper, canvas, wall clothing, color coating glaze, shell powder, color grain paint, etc.

High Precision Wall Inkjet Printer USA Senor Piezoelectric Nozzle Automatic Feeder System

※Technical Data Of Wall Printer

Model PE-S70 PE-S80
Printing Head Japan imported industrial grade printing head
1 pc 2 pcs
Painting Speed 32㎡/h 64㎡/h
Main-board Configuration 6-core CPU, 2GB DDR memory 8-core CPU, 4GB DDR memory
UPS Battery Life About 10 hours About 12 hours
Pad Size 10.1 inch 11.6 inch
Rail Size(L×H) 4500mm×2500mm
Host Size (L×W×H) 400mm×320mm×2640mm
Sensor Double
X Axis Effective Stroke 2000mm
Y Axis Effective Stroke Unlimited
Z Axis Effective Stroke 150mm
Z Axis Guide 170mm
Z Axis Automatic Have
Ink Consumption Per Square 6-10ML
Nozzle Protective Device Have
Spirit Level Have
Automatic White Jump Have
Nozzle Cleaning One Key Automatic
Painting Accuracy 9600DPI
Painting Direction Vertical
Painted Mode two-way
Ink Tank Capacity 400ML=100ML×4
Spray Distance 0.5-2.0cm
Ink Supply Method Automatic ink supply under negative pressure
Data Transmission Method USB2.0/3.0
Certification CE/GB18582-2001/GBT9756-2001
Power Supply AC110V (90-132V)/AC220V (180-264V) , 47-63HZ
Power Consumption No load:20W, Generally:75W, MAX: 250W
Noise Standby <20dBA, Drawing <50dBA
Working Temperature -10°C-60°C (14°F-140°F) 10%-80% relative humidity, non-condensing
Storage Temperature -30°C-60°C (-22°F-140°F) 10%-80% relative humidity, non-condensing
Language Chinese and English (Customized)
Total Body Weight 30 kgs 32 kgs
Total Track Weight 26.5 kgs 38 kgs
Training VCD training, Engineer overseas training is available (charged additionally)
Guarantee 12 months

※Samples Show Of Wall Printer

High Precision Wall Inkjet Printer USA Senor Piezoelectric Nozzle Automatic Feeder System

High Precision Wall Inkjet Printer USA Senor Piezoelectric Nozzle Automatic Feeder System

※Packaging & Delivery

1. Prompt deliver at the very day.

2. Sophisticated and professional logistic agent.

3. Well-trained and disciplined packing team.

4. After-sale service:. Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.

※Competitive Advantages

1. We offer high quality products at competitive price in quick delivery.

2. 100% custom pass guaranteed.

3. Good after-sale service.

4. Flexible and Untraceable payment terms.

5. Our products have been exported to Germany, Norway, Poland, Finland, Spain, UK, France, Russia, USA, Brazil, Mexico, Australia, Japan, Korea, Thailand, Indonesia, Uruguay and many other countries.
