20W 30w 50w CO2 Fly Laser Marking Machine For Plastic
20W 30w 50w CO2 Fly Laser Marking Machine For Plastic
20W 30w 50w CO2 Fly Laser Marking Machine For Plastic
20W 30w 50w CO2 Fly Laser Marking Machine For Plastic
Specifications
Place of Origin :
CHINA
Certification :
ISO,CE
MOQ :
1 set
Price :
Negotiation
Packaging Details :
Wooden cases standard export package
Delivery Time :
5-7 working days
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
200-500 Sets/Month
Name :
flying fiber laser marking machine
Laser Type :
CO2 laser
Application :
Laser Marking
Weight (KG) :
52 KG
Key Selling Points :
Easy to Operate
Laser power :
20W /30w/ 50w(Optional)
Marking Speed :
≤18000mm/s (according to different material)
Applicable Material :
Metal Plastic
Marking Area :
50mm X 50mm~175mm X 175mm )
Laser wavelength :
1064nm
Working Accuracy :
0.01mm
Core Components :
Pressure vessel
Description

20W 30w 50w CO2 Fly Laser Marking Machine For Plastic

Description

1. The machine takes CO2 glass laser tube as the light source. By 2D fast-speed scanning lens swinging as the scheduled angles under the controlling of the computer, the laser focus on the surface of the work piece by F-θ lens to form images and realize marking and graph processing.
2. The CO2 laser marking machine has the longest application time and the most extensive usage areas and is the most mature technology at present.
3. By using fast-speed scan lens, it can scan the graph in shortest time finish fine marking process.
4. It can configure auto clamp and baiting production line as user’ s requirements.
5. It can mark data, series number bar code automatically.
6. It is available for data communications, networking.

Laser Type

CO2 laser

Laser Wavelength

10.6 μm

Laser Power

10W/30W/60W/100W

Cooling Method

Air cooling

Power Consumption

500W~1000W(220VAC,50HZ)

Marking Focal Length

100mm~190mm

Positioning Accuracy

0.01mm

Min Line Width

0.1mm

Marking Area

50mm X 50mm~175mm X 175mm or other customized

Assembly Line Speed Support

0~189m/min

Marking Speed

≤18000mm/s (according to different material)

Character Size

Adjustable in Marking Range

Marking Line number

Adjustable in Marking range

Marking Content

Chinese and English Character/Numbers/Graphics/Date and Time/Serial Number, etc

Marking Font

All kinds of standard CAD geometric font, also can be user-defined extended.

Laser source

US Synrad

Galvanometer scanner

German Scanlab/US CTI
