High Safety Handheld Laser Welding Equipment High Cooling Rate Environmentally Friendly
High Safety Handheld Laser Welding Equipment High Cooling Rate Environmentally Friendly
Specifications
Brand Name :
Huahai laser
Model Number :
HB-FW500-F; HB-FW750-F;HB-FW1000-F
Certification :
CE FDA
Place of Origin :
Wuhan China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
200 sets/ Month
Delivery Time :
5-10 working days
Packaging Details :
Wood Package
Output Power :
500W 750W 1000W
Laser Wavelength :
1070nm
Power Supply :
220V+_10, 50/60hz ; 380V+_10, 50/60hz
Line Width :
<4-5nm
Description

Huahai Laser Handheld Laser Welding Equipment for Stainless Steel , Metal , Carbon Steel

(HB-FW500-F; HB-FW750-F;HB-FW1000-F)

Advantage:

Welding with high speed;
welding seams appearance;
beautiful smooth weld;
without secondary processing, saving time and cost handheld welding head;
simple and flexible, long distance welding, welding the workpiece at any angle without distortion, black, no burr;
a small welding heat affected area less laser welding consumables;
long life, safer and more environmentally friendly

Features:

1. The energy density is high, the heat input is low, the amount of thermal deformation is small, and the melting zone and the heat-affected zone are narrow and deep.

2. High cooling rate, which can weld fine weld structure and good joint performance.

3. Compared with contact welding, laser welding eliminates the need for electrodes, reducing daily maintenance costs and greatly increasing work efficiency.

4. The weld seam is thin, the penetration depth is large, the taper is small, the precision is high, the appearance is smooth, flat and beautiful.

5. No consumables, small size, flexible processing, low operating and maintenance costs.

6. The laser is transmitted through fiber optics and can be used in conjunction with a pipeline or robot.

Application areas:

It is widely used in the kitchenwares, metal industry, automotive, machinery manufacturing, medical equipment, shipbuilding, chemical industry, aerospace, aviation, power battery and daily necessities industries.

Parameters:

1 Device Name Handheld Fiber laser welder
2 Laser power 500W, 800W, 1000W
3 Laser wavelength 1070 NM
4 Fiber length Standard support up to 10M 15M
5 Way of working Continuous / modulator
6 Welding speed range 0 ~ 120 mm / s
7 Cooling Water Industry heated water tanks
8 Operating temperature range 15 ~ 35 ℃
9 Operating humidity range <70% non-condensing
10 Welding thickness recommendations 0.5-3mm
11 A weld gap requirements ≤0.5mm
12 Operating Voltage 220 V / 380V

Samples:

High Safety Handheld Laser Welding Equipment High Cooling Rate Environmentally Friendly
