Eyewear Repair Jewelry Laser Welding Machine 150W Good Corrosion Resistance
Eyewear Repair Jewelry Laser Welding Machine 150W Good Corrosion Resistance
Specifications
Brand Name :
HUAHAI LASER
Model Number :
HB-SW150
Certification :
CE , FDA
Place of Origin :
CHINA
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
200sets per month
Delivery Time :
7-10 working days
Packaging Details :
standard export wooden case
Laser source :
YAG Plused
Laser Power :
150w
Laser wavelength :
1064nm
Warranty period :
1 year
Voltage :
220V or 110V 50/60kHZ
Cooling Mode :
water cooling
Consumables :
xenon lamps, protective lens
Application :
gold, platinum, titanium, silver, copper, nickel, aluminum, magnesium, stainless steel, etc.
Description

150W Mini Portable Laser Spot Welding Machine For Jewelry Eyewear Welding Repairing

Product Introduction

SW series laser spot welder is firstly designed for jewelry ornaments manufacturing, jewelry repairing, rings or bracelets resizing, gold and silver re-tipping, stone setting, eyewear welding or repairing, denture welding, small auto parts welding, etc. Generally, it is especially suitable for tiny target precision welding. It works on gold, platinum, titanium, silver, copper, nickel, aluminum, magnesium, stainless steel, etc.

Features Of Jewelry Laser Spot Welding Machine

● Energy, pulse width, frequency and focus can be adjusted within a wide range to achieve different welding effects.
● Ceramic reflector used in the laser pump chamber is imported, which is corrosion resistant, high temperature resistant, high electrical/optical conversion.
● World-leading automatic light shielding system is employed to remove harmful lighting on eyes during operation.
● 24-hour continuous operation, with stable operating performance,
● Free of maintenance within 10000 hours.
● Personalized design in compliance with ergonomics principles.

Main Structure & Maintenance

The whole system is composed of:

A. Laser Generator B. Laser Power C. Optical System

D. Control system E. Cooling system

Operation

Step 1) Start the chiller and wait for 1-2 minutes until the water temperature reaches the target value you set. Normally 25 Celsius Degrees.

Step 2) Turn on the air switch behind the welder

Step 3) Twist the key switch to start laser welder

Step 4) Press “OK” button on control panel, the word OPEN turns into CLOSE. Set parameters correctly based on the type of material and the result of test shooting. Sometimes it relies more on operator’s experience.

Step 5) Turn on the LED light and adjust the position of cover gas nozzle before welding so that your work piece can be prevented from quick oxidation. You can also change all parameters by the joystick inside the welding chamber or stop welding immediately by the emergency button.

Step 6) Now you are free to weld.

step 7) When you finish welding, move the dash on CLOSE, press OK button, turn off the key switch, turn off the chiller and cut the total power. Finally, please open the protective cover and clean the dusts in the welding chamber. We strongly suggest you to do this at least once a week.

Technical Parameters

Laser Source: Nd3+:YAG

Wavelength: 1064nm

Pulse frequency: 1~50Hz adjustable

Pulse width: 1.5~20ms adjustable

Single pulse Energy: 60 J

Rated Laser Power: 150W

Max Single Power: 180 W

Cover Gas Channel: 1 line quick connection

Focused Beam Diameter: 0.1~3mm

Expanding Ratio: 3

Focal Length: 100mm

Power Supply: Single phase AC 220V±10%

Peak Power: 6kW when starting/2-4kW when welding

Standby Power: 0.3-0.5kW

Running Environment: Temperature 10℃~32℃, humidity < 85%.

Continuous Working Time: 24 hours

Sample show

Eyewear Repair Jewelry Laser Welding Machine 150W Good Corrosion Resistance
