Security Seals UV Laser Marking Machine , Yag Laser Marking Machine Easy Operation
Security Seals UV Laser Marking Machine , Yag Laser Marking Machine Easy Operation
Security Seals UV Laser Marking Machine , Yag Laser Marking Machine Easy Operation
Security Seals UV Laser Marking Machine , Yag Laser Marking Machine Easy Operation
Security Seals UV Laser Marking Machine , Yag Laser Marking Machine Easy Operation
Security Seals UV Laser Marking Machine , Yag Laser Marking Machine Easy Operation
Specifications
Brand Name :
Huahai Laser
Model Number :
HM Series
MOQ :
1set
Payment Terms :
T/T, Western Union
Delivery Time :
7-10 work days
Packaging Details :
Wooden case
Certification :
CE FDA
Place of Origin :
Wuhan,China
Price :
Negotiable
Supply Ability :
100sets/month
Engraving Area :
200mm*200mm
Wavelength :
355nm
Marking Speed :
0-7000mm/s
Laser type :
UV laser
Marking area :
110*110mm to 200*200mm
Warranty :
1 year
Description

Laser Printing 5W 10W 7W 3W Mini Portable Security Seals 355nm UV Laser Marking Machine For Plastic Glass Frame

Product Applicate

Mainly based on its unique low-power laser beam. It is especially suitable for the high-end market of ultra-fine processing. The surfaces of bottles for cosmetics, pharmaceuticals, food and other high-molecular materials are marked with fine effects and clear and firm markings. Better than ink coding and no pollution; flexible pcb board marking, dicing; silicon wafer micro hole, blind hole processing; LCD liquid crystal glass two-dimensional code marking, glass surface punching, metal surface coating marking, Plastic buttons, electronic components, gifts, communications equipment, building materials, and so on.

UV laser marking machine widely used in 3C industry marking, as well as industrial micro machining, including marking for a diversity of materials, plastic,glass, LED scribing, laser rapid prototyping, removal of metal and non-metal coating, silicon wafer processing and so on.

Product advantages

1) High marking precision
2) Free maintenance, easy to operation
3) Excellent Laser beam quality
4) Long life,laser generator life over 25,000 hours
5) Humanized design,convenient installation
6) Low power consumption,stability laser output
7) High electronic conversion efficiency
8) Import high speed galvo scanner system
9) FDA certificate, No Laser Additives added
10) Desktop/ flying, CO2/ Fiber/ UV,Chinese/ imported Laser optional.

Machine features

1) UV laser with stable water-cooling.

2) UV laser temperature control PID with high precision.

3) Choose a variety of modes for first pulse suppression, to achieve the best inhibitory effect.

4) UV laser can offer a variety of different average laser power and pulse width, fit for different processing requirement.

Technical Parameters

Machine model

HM03/05P

HM10/15P

Wavelength(nm)

355nm

Pulse repetition rate(kHz)

20-100

50-100

Pulse Width(ns)

<20ns O30KHZ

<25ns@10KHZ

Average Power(W)

2.0-3.0@30kHz

4.0-5.0@40kHz

7.0-8.0@50kHz

Average Power Stability

±2%over8 hours

Pulse-to- Pulse instability

< 3% rms

Spatial Mode

TEMOO(M2 <1.3)

Beam Divergence

<2 mrad(Full Angle)

1/e2 Beam Diameter

0.6±0.1mm

Beam Roundness

>90%

Pointing stability

<50urad

Polarization Direction

Horizontal

Polarization Ratio

100:1

Cooling

air-cooling

water-cooling

Ambient Temperature(℃)

15-30

Storage Temperature(℃)

-10-50

Relative humidity

10%-80%(non-condensing)

Warm-up Time(mins)

<10

Operating Voltage(V)

90-260

Warranty

12months

12 months

Marking depth

0.5mm

Graphic format supported

AI ,PLT ,BMP,JGP,PNG,DXF, etc.

Our service

1, Free Pre-Sales Consulting / Free Sample Marking

2, Strict Quality Control of Production
3, 5-7 Days Quick Delivery
4, 1 Year Quality Guarantee
5, 12 hours Quick Feedback & After-Sales Service
6, Quick Back-up Parts Available & Technical Assistance
7, Free Training Service

Samples

Security Seals UV Laser Marking Machine , Yag Laser Marking Machine Easy Operation

Security Seals UV Laser Marking Machine , Yag Laser Marking Machine Easy Operation
