DWDM MUX DEMUX 8CH (C21-C28) with Express Port LC/UPC Dual Fiber LGX BOX
DWDM MUX DEMUX 8CH (C21-C28) with Express Port LC/UPC Dual Fiber LGX BOX
DWDM MUX DEMUX 8CH (C21-C28) with Express Port LC/UPC Dual Fiber LGX BOX
DWDM MUX DEMUX 8CH (C21-C28) with Express Port LC/UPC Dual Fiber LGX BOX
DWDM MUX DEMUX 8CH (C21-C28) with Express Port LC/UPC Dual Fiber LGX BOX
DWDM MUX DEMUX 8CH (C21-C28) with Express Port LC/UPC Dual Fiber LGX BOX
DWDM MUX DEMUX 8CH (C21-C28) with Express Port LC/UPC Dual Fiber LGX BOX
DWDM MUX DEMUX 8CH (C21-C28) with Express Port LC/UPC Dual Fiber LGX BOX
Specifications
MOQ :
1
Description

8 Channels C21-C28 DWDM MUX DEMUX Dual Fiber with Expansion Port LC/UPC LGX BOX

Product Details

Operating Wavelength 8 Channels C21-C28 Channel Spacing 100GHz
Passband ITU±0.11 Insertion Loss ≤ 2.4dB
Directivity ≥50dB Return Loss ≥45dB
Passband Ripple ≤ 0.5dB Fiber Type SMF-28e+
Adjacent Channel Isolation ≥30dB Non-adjacent Channel Isolation ≥40dB
Polarization Dependent Loss ≤0.2dB Polarization Mode Dispersion ≤0.2ps
Maximum Optical Power 500mW Dimensions (HxWxD) 39x208x200mm
Operating Temperature -20°C～+75°C Storage Temperature -40°C～+85°C
