3m (10ft) MTP Female to 4 LC UPC Duplex OS2 9/125 Single Mode Fiber Breakout Cable, 8 Fibers, Type B, Elite, Plenum (OFNP), Yellow
3m (10ft) MTP Female to 4 LC UPC Duplex OS2 9/125 Single Mode Fiber Breakout Cable, 8 Fibers, Type B, Elite, Plenum (OFNP), Yellow
3m (10ft) MTP Female to 4 LC UPC Duplex OS2 9/125 Single Mode Fiber Breakout Cable, 8 Fibers, Type B, Elite, Plenum (OFNP), Yellow
3m (10ft) MTP Female to 4 LC UPC Duplex OS2 9/125 Single Mode Fiber Breakout Cable, 8 Fibers, Type B, Elite, Plenum (OFNP), Yellow
3m (10ft) MTP Female to 4 LC UPC Duplex OS2 9/125 Single Mode Fiber Breakout Cable, 8 Fibers, Type B, Elite, Plenum (OFNP), Yellow
3m (10ft) MTP Female to 4 LC UPC Duplex OS2 9/125 Single Mode Fiber Breakout Cable, 8 Fibers, Type B, Elite, Plenum (OFNP), Yellow
3m (10ft) MTP Female to 4 LC UPC Duplex OS2 9/125 Single Mode Fiber Breakout Cable, 8 Fibers, Type B, Elite, Plenum (OFNP), Yellow
3m (10ft) MTP Female to 4 LC UPC Duplex OS2 9/125 Single Mode Fiber Breakout Cable, 8 Fibers, Type B, Elite, Plenum (OFNP), Yellow
3m (10ft) MTP Female to 4 LC UPC Duplex OS2 9/125 Single Mode Fiber Breakout Cable, 8 Fibers, Type B, Elite, Plenum (OFNP), Yellow
3m (10ft) MTP Female to 4 LC UPC Duplex OS2 9/125 Single Mode Fiber Breakout Cable, 8 Fibers, Type B, Elite, Plenum (OFNP), Yellow
Specifications
MOQ :
1
Description

Product Details

Connector AMTP Female (US Conec)Connector BLC UPC Duplex
Fiber TypeOS2 9/125μm Single ModeWavelength1310/1550nm
Fiber Count8 FibersDistance3m (10ft)
Glass FiberCorning ClearCurve®Cable JacketPlenum (OFNP)
MTP Connector IL0.35dB Max (0.15dB Typ.)LC Connector IL≤0.2dB
MTP Connector RL≥60dBLC Connector RL≥50dB
Attenuation at 1310nm≤0.32 dB/kmAttenuation at 1550nm≤0.18 dB/km
Cable Diameter3.0mmFiber ColorYellow
Fan-Out Diameter2.0mmMinimum Bend Radius10mm
Installation Tensile Load100 NLong-Term Tensile Load50 N
Operating Temperature-10°C to +70°CStorage Temperature-40°C to +85°C

Quality Assurance

Excellent quality is the foundation of FIBER MALL' s survival and development. Our operation team are experts with many years' experience in optical communication industry. Our manufacturers are first-class manufacturers in the industry. Many of them have the qualification of OEM for first-class system equipment manufacturers.

Quality Certification
We control the quality of our products, including our strict qualification of manufacturers, quality control process and production technology, and compliance with certification and safety standards. At present, our products meet the industry standards and mainstream quality certification, such as ISO 9001, CE, RoHS, FCC, etc.
