1x10/100Base-TX to 1x100Base-FX Industrial Fiber Media Converter With PoE af/at/bt Optional, FR-7N1101-SFP, -40 to 85°C
1x10/100Base-TX to 1x100Base-FX Industrial Fiber Media Converter With PoE af/at/bt Optional, FR-7N1101-SFP, -40 to 85°C
Specifications
Brand Name :
FIBERROAD
Model Number :
FR-7N1101
Certification :
CE,FCC, ROHS
Place of Origin :
CHINA
MOQ :
1-10PCS
Price :
EXW. SHENZHEN IN USD
Payment Terms :
T/T, Western Union
Supply Ability :
1000PCS PER month
Delivery Time :
3-5days
Packaging Details :
1CTN/50PCS/22.50KGS/540*315*430mm
Description

Description

FR-7N1101 with 1Port 10/100Base-TX and 1Port 100Base-FX Fast SFP that provide stable and reliable Ethernet transmission With dual power input design, FR-7N1101 can offer redundant mechanisms for critical applications that need always-on connections. It can also operate either at standard operating temperature range -40 to 85°C. Housed in rugged DIN rail or wall mountable IP40 enclosures, It is perfect choices for harsh environments, such as industrial networking, intelligent transportation systems (ITS) and are also suitable for many military and utility market applications where environmental conditions exceed commercial product specifications.

Features

- 1x10/100Base-TX RJ45 ports, 1x100Base-FX ports, 1*PoE port in Optional, Support 802.3af/at/bt

- Support Auto-MDIX, and full/half duplex self-negotiation mode

- Provide SC/FC/ST/LC interface fiber port, support single/dual fiber transmission

- Support 9K bytes giant frame, compatible with various extension protocol

- 4K MAC address table

- Support IEEE802.3az energy efficient Ethernet technology

- Support IPv6 Protocol

- Electric 4KV surge protection, easy to use in outdoor environment

- Complete status indicator, working state at a glance

- Power input polarity protection design, no worry about wrong operation

- Metal case, no fan design

- Installation method: DIN trail /Wall mounting

Specification

Physical Port
RJ45 port and speed 1x10/100Base-TX
Fiber port and speed 1x100Base-FX
Parameters

Ethernet

standards

IEEE802.3 IEEE802.3u IEEE802.3z

IEEE802.3ab IEEE802.3x IEEE802.3az

IEEE802.3Qad IEEE802.3ah IEEE802.1X

IEEE802.1Q IEEE1588
Packet buffer 1Mbits

Giant frame

 Up to 9K Bytes
MAC address table 4K
Transmission mode Store and Forward(full/half duplex mode)
Exchange property

Delay time: < 7μs

Backplane bandwidth: 1Gbps
LED Indicator
Power Connect-always
RJ45

Link/Act: connect-always; data exchange-twinkle

Speed light: 100Mbps-always; 10Mbps-twinkle
Fiber Link/Act: connect-always; data exchange-twinkle
Power Information
Power access mode Phoenix terminal
Redundant power input DC 9-56V
Physical Property
Protection grade IP40 aluminum case
Cooling mode Natural cooling, no fan design
Dimensions 120mm x 89mm x 35mm (L x W x H)
Installation mode DIN trail/wall-mountable
Weight 400g
Working Environment
Operating Temperature -40℃~85℃
Operating Humidity 5%~90% non-condensing
Storage Temperature -40℃~85℃
Warranty
MTBF 500,000 hours
Defects Liability Period 3 year warranty, lifetime technical support
Certification Standard
EMI FCC Part15 Subpart B Class A,EN 55022 Class A
EMS

EN61000-4-2(ESD), EN61000-4-3(RS),

EN61000-4-4(EFT), EN61000-4-5(Surge),

EN61000-4-6(CS), EN61000-4-8,

EN61000-4-11
Collision IEC60068-2-27
Drop IEC60068-2-32
Vibration IEC60068-2-6
Safety grade EN60950-1

Package List

- 1 x Fiber Media Converter

- 1 x Rail Mounting Kit

- 1 x Wall Mount Kit

- 1 x Warranty Card

Order Information

FR-7N1101-SFP 1x10/100Base-TX to 1x100Base-FX SFP Slot Industrial Fiber Media Converter
FR-7N1101-S3S20 1x10/100Base-TX to 1x100Base-FX (SM Duplex 20km SC) Industrial Fiber Media Converter
FR-7N1101P 1x10/100Base-TX to 1x100Base-FX Industrial Fiber Media Converter With PoE af/at
