2x16 Single Mode Fiber Splitter
2x16 Single Mode Fiber Splitter
2x16 Single Mode Fiber Splitter
2x16 Single Mode Fiber Splitter
2x16 Single Mode Fiber Splitter
2x16 Single Mode Fiber Splitter
2x16 Single Mode Fiber Splitter
2x16 Single Mode Fiber Splitter
Specifications
Brand Name :
UT-King
Model Number :
PLC-C216LA
Certification :
CE.ROSH,ISO9001
Place of Origin :
China
MOQ :
2 PCS
Payment Terms :
T/T, Western Union,Credit Card,
Supply Ability :
10000pcs/per week
Delivery Time :
3-5 workdays
Packaging Details :
1 pcs 1 Plastic boxes
Product Name :
PLC splitter
Type :
Cassette Type 2x16
Application :
FTTH FTTX Solution
Fiber type :
G657A1
Connector type :
LC/APC
Wavelength :
1260-1650nm
Item :
Cassette Fiber spliter
Insertion loss :
14.1dB
Model :
SM/MM
Splitter Ratio :
2*16
Keywords :
Cassette PLC Splitter
Description

2x16 PLC Splitter Fibre Separation Single Mode Fiber Splitter 2*16 LGX LC Connector

Description

UT-King Card Type Optical fiber splitter is a type of optical power management device that is fabricated using silica optical waveguide technology.

PLC splitter is based on a quartz substrate integrated waveguide optical power distribution device, has the advantages of small volume, the working wavelength range, high reliability, good light uniformity etc characteristic, is especially suitable for passive optical network ( EPON,BPON,GPON etc ) connected local and terminal equipment and realize the optical signal devide.

UT-King provides whole series of 1xN and 2xN splitter products that are tailored for specific applications. All products meet GR-1209-CORE and GR-1221-CORErequirements.We produce all kinds of PLC splitters of fiber optic and sell at home and aboard: mini module type, LGX module type, steel tube type, bare fiber type, ABS plastic module type, Rack type, fusion module tray type, splitter closure type... etc.

Features

  • Low Insertion loss
  • Low PDL
  • Compact Design
  • Good channel-to-channel uniformity
  • Wide Operating Wavelength: From 1260nm to 1650nm
  • Wide Operating Temperature: From -40°C to 85°C
  • High Reliability and Stability

Application

  • Fiber to The Home (FTTH)
  • Passive optical networks (PON)
  • Local Area Networks (LAN)
  • Cable Television (CATV)
  • Test Equipment

Specification

Item

1x2

1x3

1x4

1x6

1x8

1x12

Operating Wavelength(nm)

1260-1650

Fiber Type

G657A1 or as customers' order

Connector

SC/FC/LC

Ferrule section

UPC/APC

Insertion loss(dB)

≤4.1

≤6.4

≤7.4

≤9.3

≤10.5

≤12.8

Loss uniformity(dB)

≤0.4

≤0.4

≤0.6

≤1.6

≤0.8

≤1.2

Return Loss(dB)

≥55

≥55

≥55

≥55

≥55

≥55

Polarization Dependent Loss(dB)

≤0.2

≤0.2

≤0.2

≤0.2

≤0.2

≤0.25

Directivity(dB)

≥55

≥55

≥55

≥55

≥55

≥55

Temperature correlation loss

-40～85℃(dB)

≤0.5

≤0.5

≤0.5

≤1.5

≤0.5

≤0.5

Size(mm)(LxWxH)

40×4×4

60×7×4

Working Temperature(℃)

-40～85

Storage Temperature(℃)

-40～85

Item

1x16

1x24

1x32

1x48

1x64

1x128

Operating Wavelength(nm)

1260-1650

Connector

SC/FC/LC

Ferrule section

UPC/APC

Fiber Type

G657A1 or as customers' order

Insertion loss(dB)

≤13.8

≤15.8

≤16.8

≤18.7

≤20.5

≤24.1

Loss uniformity(dB)

≤1.2

≤1.5

≤1.5

≤2.0

≤2.0

≤2.5

Return Loss(dB)

≥55

≥55

≥55

≥55

≥55

≥55

Polarization Dependent Loss(dB)

≤0.25

≤0.3

≤0.3

≤0.4

≤0.4

≤0.4

Directivity(dB)

≥55

≥55

≥55

≥55

≥55

≥55

Temperature correlation loss

-40～85℃(dB)

≤0.5

≤0.5

≤0.5

≤1.5

≤0.5

≤0.5

Size(mm)(LxWxH)

60×7×4

60×12×6

N/A

Working Temperature(℃)

-40～85

Storage Temperature(℃)

-40～85

Item

2x2

2x4

2x8

2x16

2x32

2x64

2x128

Operating Wavelength(nm)

1260-1650

Fiber Type

G657A1 or as customers' order

Connector

SC/FC/LC

Ferrule section

UPC/APC

Insertion loss(dB)

≤4.5

≤7.9

≤10.8

≤14.1

≤17.3

≤21.1

≤24.8

Loss uniformity(dB)

≤0.9

≤1.1

≤1.2

≤1.5

≤1.8

≤2.2

≤2.5

Return Loss(dB)

≥55

≥55

≥55

≥55

≥55

≥55

≥55

Polarization Dependent Loss(dB)

≤0.2

≤0.2

≤0.3

≤0.3

≤0.4

≤0.4

≤0.4

Directivity(dB)

≥55

≥55

≥55

≥55

≥55

≥55

≥55

Temperature correlation loss

-40～85℃(dB)

≤0.5

≤0.5

≤0.5

≤1.5

≤0.5

≤0.5

≤0.5

Size(mm)(LxWxH)

50×4×4

60×7×4

N/A

Working Temperature(℃)

-40～85

Storage Temperature(℃)

-40～85

2x16 Single Mode Fiber Splitter2x16 Single Mode Fiber Splitter2x16 Single Mode Fiber Splitter2x16 Single Mode Fiber Splitter
