Specifications
Brand Name :
UT-King
Model Number :
GP4104
Certification :
CE,ROHS,ISO9001
Place of Origin :
China
MOQ :
10
Payment Terms :
Western Union, T/T
Supply Ability :
1000 pcs/week
Delivery Time :
7-10 work days
Packaging Details :
1pcs/box
Product name :
GPON ONU
function :
1ge Port
Type :
gpon onu
Power supply :
12V 0.5A
PON Port :
1GE PON Port
Name :
1ge gpon onu
Connector Type :
SC/UPC or SC/APC
Downlink :
1*10/100/1000Mbps auto adaptive
Application :
FTTB/FTTH/FTTO
Chipset :
ZTE/RTL/MTK
Description

Gpon Onu FTTX FTTB FTTX Fiber Optical Network ONU GPON 1Ge Port

The GPON ONU integrates GPON OMCI Stack and is fully compliant with ITU-T G.984 standards. The ONU is in a standardized MSA SFP form-factor and is designed to simply plug into a standard SFP port in your router.

1. Overview

  • UT-GP4104 series single-user ONU is designed for ONU in deferent FTTH solutions by UT-King, The carrierclass FTTH application
  • provides date service access.
  • UT-GP4104 series adopts high-performance and low-consumption chips, and supports CTC 3.0
  • interconnection and interworking standard of China Telecom. With the help of NGBN View NMS, it can provide subscribers with
  • abundant services, and totally meet the needs of carrier-class FTTH devices.
  • UT-GP4104G series is designed by ZTE chipset.


2. Functional Feature

●Router mode supports PPPoE/DHCP/ static IP
●Support port-based rate limitation and bandwidth control;
●In compliant with IEEE802.3ah Standard
●Up to 20KM transmission Distance
●Support data encryption, group broadcasting, port Vlan separation, etc.
●Support Dynamic Bandwidth Allocation (DBA)
●Support ONU auto-discovery/Link detection/remote upgrade of software;
●Support VLAN division and user separation to avoid broadcast storm;
●Support power-off alarm function ,easy for link problem detection
●Support broadcasting storm resistance function
●Support ACL and SNMP to configure data packet flter flexibly
●Specialized design for system breakdown prevention to maintain stable system Support software online upgrading EMS network management based on SNMP ,convenient for maintenance

Model No. UT-GP4104
Interface

1 *SC/UPC Port or 1 *SC/APC Port;

1 *10/100/1000Mbps RJ45 Port
Chipset Realtek, RTL9601D+RTL8290B
Data Rates & Wavelength

Upstream:1.244Gbps, 1310nm

Downstream:2.488Gbps, 1490nm
Distance 0~ 20Km Max
External Power Supply DC 12V/0.5A
Dimensions (Length * Width * Height) 132mm×100mm×30mm
Weight (Full-Loaded) ≤0.3kg
Working temperature 0°C～40°C
Storage temperature: -40°C～70°C
Relative humidity: 10%～90%, non-condensing

FTTB Optical Network Terminal Modem UPC SC Ont Optical ModemFTTB Optical Network Terminal Modem UPC SC Ont Optical ModemFTTB Optical Network Terminal Modem UPC SC Ont Optical ModemFTTB Optical Network Terminal Modem UPC SC Ont Optical Modem
