APC UPC Singlemode Multimode Fiber Optic Patch Cord
APC UPC Singlemode Multimode Fiber Optic Patch Cord
APC UPC Singlemode Multimode Fiber Optic Patch Cord
APC UPC Singlemode Multimode Fiber Optic Patch Cord
APC UPC Singlemode Multimode Fiber Optic Patch Cord
APC UPC Singlemode Multimode Fiber Optic Patch Cord
APC UPC Singlemode Multimode Fiber Optic Patch Cord
APC UPC Singlemode Multimode Fiber Optic Patch Cord
Specifications
Brand Name :
FUJI
Certification :
iSO,CE,ROHS
Place of Origin :
CHINA
MOQ :
100pcs
Price :
Negotiable
Supply Ability :
10000pcs
Delivery Time :
5-7 working days
Packaging Details :
PE Bag and Carton
Product name: :
Fiber Optic Patch Cord
Application: :
FTTH FTTB FTTX Network
Fiber Type: :
G652D, G657A1
RL: :
≥65dB
IL: :
≤0.2dB
Keywords: :
ftth fiber optic patch cord
Material: :
LSZH/PVC
Connector Type: :
SC FC LC ST
Description

Fiber Optic Patch Cord Cable SC/LC/FC/ST Connector APC UPC Singlemode Multimode Pigtail

Ftth SC FC APC UPC Fiber Optic Patch Cord Cable

Feature:

Price-Competitive
Low Insertion Loss & PDL
Factory-terminated and Tested
Fiber Options: G.652D /G.657A1/OM1/OM2/OM3 and PM Panda Fiber
Connector Options: FC/SC/LC/ST/MU/E2000/MT-RJ/MPO/MTP
Polishing Options: PC/UPC/APC
Feature Connector with Ceramic FerrulesApplications

Specifications:

Item SM MM
Type FC/APC FC/UPC FC/APC FC/UPC
SC/APC SC/UPC SC/APC SC/UPC
ST/APC ST/UPC
Return Loss >=55dB >=50dB >=60dB >=35dB
Insertion Loss <=0.2dB
Operating Temperature -40°C ~ +80°C
Repeatability <=0.1dB
Interchangeability <=0.2dB
Insertion and Pull Times 1000
Tensile Strength >100N

FAQ:
Q1:What is your main products?
A:Main products:high density multi-core connector, 40G/100G/200G/400G module connector, module/device test standard line, bus bar for test equipment, jumper calibration line, polarization-maintaining product, optical fiber connector, passive device test equipment, passive device production equipment, passive device clamp design, passive device production consumables, and active module OEM/ODM service.

Q2. What is your payment terms?
A: Full payment in advanced. We'll show you the prepared photos of the products and packages before you pay the balance.

Q3. Can we get free samples?
A:Sorry,it is not available for initial order.

Q4What is your terms of trade?
A: We offer EXW,FOB,CIF and CNF or as your request.


Q5. How about your delivery time?
A: Generally, it will take 3 to 5 days after receiving your deposit. The specific delivery time depends on the items and the quantity of your order.Large quantity will delivery faster.

Q6. Do you test all your goods before delivery?
A:Yes, we have professional engineer to test all devices before shipping.
