SC - LC Fiber Optic Jumper Cables Violet / Purple OM3 50/125 Cable
SC - LC Fiber Optic Jumper Cables Violet / Purple OM3 50/125 Cable
SC - LC Fiber Optic Jumper Cables Violet / Purple OM3 50/125 Cable
SC - LC Fiber Optic Jumper Cables Violet / Purple OM3 50/125 Cable
SC - LC Fiber Optic Jumper Cables Violet / Purple OM3 50/125 Cable
SC - LC Fiber Optic Jumper Cables Violet / Purple OM3 50/125 Cable
SC - LC Fiber Optic Jumper Cables Violet / Purple OM3 50/125 Cable
SC - LC Fiber Optic Jumper Cables Violet / Purple OM3 50/125 Cable
Specifications
Brand Name :
Fujioptics/OEM/ODM
Model Number :
FJ-SC01ee
Certification :
ROHS.CE ,ISO9001
Place of Origin :
CHINA
MOQ :
100pcs
Price :
Negotiation
Payment Terms :
L/C, D/P, Western Union
Supply Ability :
10000pcs
Delivery Time :
5-7 working days
Packaging Details :
PE bag ,Carton box
Connector Type :
LC-ST
Fiber Type :
OM3/OM4
Cable Type :
Duplex
Cable OD :
2.0mm
Cable Jacke :
PVC/LSZH/OFNP
Cable Color :
Aqua, Purple, Violet Or Customized
High Light :
fiber optic jumper, fiber optic cable patch cord
Description

SC - LC Fiber Optic Patch Cord , Violet / Purple OM3 50/125 Cable


Description:

Fiber Optic Patch Cables are available in both multimode and single mode cable types, in Simplex and Duplex version.

Fiber optic patch cord is suited for equipment jumper cable, cross connects, and work area connections.


All fiber optic patch cords are manufactured with telecom class and polished A, and 100% factory tested to ensure performance to TIA/EIA-568-B-3 standards.

Features:

Good durability

Good exchangeability
High temperature stability
Price Competitive

Factory-terminated and Tested

Application:

Local Ring Network
Optical Fiber Sensor
Telecom Network
Optical Fiber Test Equipment
FTTH,LAN,PON & Optical CATV

Specification:

Mode SM MM
Polishing PC APC UPC PC UPC
Insertion Loss ≤0.3dB UPC≤0.3dB APC≤0.3dB APC≤0.3dB APC≤0.3dB
Return Loss PC≥52dB APC≥65dB UPC≥55dB PC≥35dB UPC≥35dB
Exchangeability ≤0.2dB
Salt Spray ≤0.2dB
Vibration (550Hz 1.5mm) ≤0.1dB
Apex Offset 0μm≤≤50μm
Radius of Curvature 7mm≤≤25mm
Humidity (+25+65 93 R.H.100 hours) ≤0.2db
Cable Type TypeSimplex, Duplex, Fan-Out
Connector Type LC,SC,FC,ST, MU, MPO, MTRJ,DIN, SMA, FDDI


Order Information:

FC/PC-FC/PC-SM-SX-φ3.0-3M

  1. Connector Type:FC, SC, LC, ST, MPO, MTRJ, MU, D4, DIN, SMA
  2. Ferrule End-face:PC, UPC, APC
  3. Core Type: Single-mode(SM:9/125μm), Multimode(MM:50/125μm or 62.5/125μm)
  4. Product Structure:“DX”means Duplex, “SX”means Simplex
  5. Fiber Diameter: φ3.0mm, φ2.0mm, φ0.9mm
  6. Cable Length:1, 2, 3meter or customized.
  7. Cable Type: PVC,LSZH, OFNR, OFNP

Product Picture:

SC - LC Fiber Optic Jumper Cables Violet / Purple OM3 50/125 Cable
