50um 62.5um Multimode LC OFC Pigtail With White Red Black Boot
50um 62.5um Multimode LC OFC Pigtail With White Red Black Boot
Specifications
Brand Name :
Fujioptics/OEM/ODM
Model Number :
FJ-SC05
Certification :
ROHS.CE ,ISO9001
Place of Origin :
CHINA
MOQ :
100pcs
Price :
Negotiation
Payment Terms :
L/C, D/P, Western Union
Supply Ability :
10000pcs
Delivery Time :
5-7 working days
Packaging Details :
PE bag ,Carton box
Connector Type: :
LC
Ferrule End-face: :
UPC/PC
Fiber Type: :
OM1 OM2
Cable Type: :
Simplex
Cable OD: :
0.9/2.0/3.0mm
Cable Jacket: :
PVC/LSZH/OFNR/OFNP Outer Jacket
Cable Length: :
1M, 2M, 3M Or Customized
Description

50um 62.5um Multimode LC Fiber Pigtail With White Red Black Boot, OFC Pigtail

Features:

Fiber Options: G.652 /G.657/OM1/OM2/OM3 and PM Panda Fiber

Connector Options: FC/SC/LC/ST/MU/MT-RJ/MPO/MTP

Polishing Options: PC/UPC/APC

Feature Connector with Ceramic Ferrules

Price-Competitive

Low Insertion Loss & PDL

Factory-terminated and Tested

Application:

Premise installations

Wide Area Networks (WANs)

Telecommunication networks

Active device termination

Local Area Networks (LANs)

Data processing networks

Test equipment

Specification:

Style LC,SC,ST,FC.MU,MPO, SC/APC,FC/APC,LC/APC.MU/APC Duplex MTRJ/Female, MTRJ/Male
Fiber Type

9/125 SMF-28 or equivalent (Singlemode) OS1 50/125, 62.5/125 (Multimode) OM2&OM1 50/125,

10G (Multimode) OM3
Cable Type

Simplex, Duplex (Zipcord) Φ3.0mm, Φ2.0mm, Φ1.8mm Φ1.6mm PVC or LSZH Φ0.9mm, Φ0.6mm buffered fiber

PVC or LSZH
Polishing Manner UPC,SPC,APC (8°& 6°)
Insertion Loss ≤ 0.1dB (For Singlemode Master) ≤ 0.25dB (For Singlemode Standard) ≤ 0.25dB (For Multimode) Tested by JDS RM 3750
Return Loss (For Singlemode)

UPC ≥ 50dB SPC ≥ 55dB APC ≥ 60dB (typ.65dB)

Tested by JDS RM3750
Repeatability ±0.1dB
Operating Temperature -40C to 85C
Geometry Requirement (For Singlemode) Ferrule Endface Radius 7mm ≤ R ≤ 12mm (For APC) 10mm ≤ R ≤ 25mm (For Standard) Apex Offset ≤ 30 μm (For Master) Apex Offset ≤ 50 μm (For Standard) Undercut -50nm ≤ U ≤ 50nm Tested by DORC ZX-1


Order Information:

Boot (cable)

Size

Boot

Color

 Fiber Type Cable number Application Length
0.9mm Black 9/125μm (SM) Simplex PC Customized
2.0mm Green 50/125μm (MM) Duplex APC
3.0mm Red 62.5/125μm (MM) Fan-out (4f)
Fan-out (6f)
Fan-out (8f)
Fan-out (12f)


Product Picture:

50um 62.5um Multimode LC OFC Pigtail With White Red Black Boot
