Specifications
Brand Name :
OPTFOCUS
Model Number :
Splitter
Place of Origin :
Guangdong, China (Mainland)
MOQ :
1 pcs
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :
5
Price :
Negotiable
Name :
PLC
Certification :
ISO9001:2008
Fiber Type :
G652D
Color :
white or customized
Material :
LSZH, PVC
Connector :
SC, LC,FC,ST,MTRJ,MPO,E2000
Description

1x32 PLC Fiber Optic Splitter with sc/apc connector for CATV & FTTH

Key Features

Compact package –Convenient for Small Application & High Density Areas

Telcordia GR-1209 & GR-1221-CORE Compliant

Jacketing Material Rated to -40 to +85 °C Operating Temperature

Bend Insensitive G657A fiber

Low Insertion Loss and PDL

High Polarization Extinction Ratio & Excellent Uniformity

Offer Unique Designs and Configuartions & Support Industry Standard Applications

Applications

FTTx Deployments(GPON/BPON/EPON)

CCTV/CATV Links

Access/Metro Networks

Long Haul Telecommunications

1×N PLC Splitter Specifications

Ports 1×2 1×4 1×8 1×16 1×32 1×64
Operating Wavelength (nm) 1260~1650
Insertion Loss (dB) Max(P/S) 3.8/4.0 7.1/7.3 10.2/10.5 13.5/13.7 16.5/16.8 20.5/21.0
Loss Uniformity (dB) Max 0.6 0.6 0.8 1.2 1.5 2.5
PDL (dB) Max 0.15 0.15 0.25 0.3 0.3 0.3
Return Loss (dB) Min UPC:50 APC:55
Directivity (dB) Min 55
Standard Input Fiber Bend Insensitive SM Single Fiber(ITU G.657A)
Standard Output Fiber Bend Insensitive SM Ribbon Fiber(ITU G.657A)
Standard Output Color Blue,Orange,Green,Brown,Grey,White,Red,Black(TIA/EIA 598-B)
Max.Optical Power(mw) 300
Humidity Range(rh) 5%~85%
Operating Temperature(°C) -40~+85
Storage Temperature(°C) -40~+85
Connector Options FC/SC/LC/ST/MU/E2000
Packaging Options Bare Device*Mini Tube*ABS Module*LGX Box*19''/23'' Rack-mount
* Telcordia GR-1221-CORE&G-1209-CORE Compliant.
* Premium spec available upon request. (P/S:Premium Grade/Standard Grade)
* Typical value at +23°C without connectors losses.
