Multimode / Single Mode Fiber Cable , 1-12Cores Armored Fiber Cable Indoor
Multimode / Single Mode Fiber Cable , 1-12Cores Armored Fiber Cable Indoor
Specifications
Brand Name :
HG or OEM
Model Number :
GJJZS
Certification :
ISO9001
Place of Origin :
China
MOQ :
10KM
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
2000KM Per Day
Delivery Time :
5-7 working days
Packaging Details :
4KM/Drum
name :
Indoor Armoured Fiber Optic Cable
Model NO. :
GJJZS
Sheath Material :
Length According to Requirement Fiber Cores
Cores :
1- 12 Cores
Description

Indoor 1-12Cores Armoured Fiber Optic Cable


Armoured Fiber Optic Cable structure includes tight buffer fiber, flexible metal tube, aramid yarn and outer jacket. Its flexible armoured tube keeps the fiber protected from damage. High compression resistant, high tensile resistant, rat-bite resistant, bend resistant and optimum flexible are also its important features. Secure transmission power to avoid additional attenuation in case of bending, bundling, and heavy load. Perfectly suited for harsh environments where networking equipmentundergo repeated abuse.

Multimode / Single Mode Fiber Cable , 1-12Cores Armored Fiber Cable Indoor

Multimode / Single Mode Fiber Cable , 1-12Cores Armored Fiber Cable Indoor

Complied With Or Exceeds Standard
. ITU-T G652.D . ITU-T G651.1 OM1 OM2 OM3 OM4
. ITU-T G657.A . IEC60793-2-10 type A1a.1/A1b OM1/OM2
. IEC60793-2-10 type A1a.2 OM3 . IEC60793-2-10 type A1a.3 OM4
. ISO/IEC 11801 , ISO/IEC 24702 . IEEE 802.3z Gigabit Ethernet
. ANSI/TIA/EIA 568C.3 . ROHS Compliant Directive 2011/65/EU(ROHS2.0)

Mechanical & Environmental Characteristics
ITEM Value
Max. Tensile Load (Short Term) 800N
Max. Tensile Load (Long Term) 400N
Max. Crush Load (Short Term) 1000N/100mm
Max Crush Load (Long Term) 500N/100mm
UL Fire Rated OFNR
Operating Temperature -20°C to +60°C
Storage Temperature -40°C to +85°C
Sheath Material Standard: PVC
Optional: LSZH,PE or other
Jacket Colour Standard: Blue (Singlemode), Gray (Multimode)
Optional: Depending on the customer's demands

ANSI/TIA/EIA-598-B Standard Fiber Color Code
Fiber Number Fiber Color Fiber Number Fiber Color
Fiber 1 Blue Fiber 7 Red
Fiber 2 Orange Fiber 8 Black
Fiber 3 Green Fiber 9 Yellow
Fiber 4 Brown Fiber 10 Violet
Fiber 5 Slate Fiber 11 Rose
Fiber 6 White Fiber 12 Aqua

Fiber 13 and higher The color code is repeated with added black stripe or dash
Note: Fiber Tube color will be followed with same order.
