Dielectric Fiber Optic Cable Loose Tube Unarmoured In / Out 4-144 Cores ISO9001 Ceritified
Dielectric Fiber Optic Cable Loose Tube Unarmoured In / Out 4-144 Cores ISO9001 Ceritified
Specifications
Brand Name :
HG or OEM
Model Number :
GYFTY
Certification :
ISO9001
Place of Origin :
China
MOQ :
2KM
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
2000KM Per Day
Delivery Time :
5-7 working days
Packaging Details :
4KM/Drum
Products :
4-144 Cores Loose Tube Unarmoured in/out Dielectric Fiber Optic Cable
Model NO. :
GYXTW
Sheath Material :
Length According to Requirement Fiber Cores
Cores :
4-144 Cores
Warranty :
2Years
Outer Jacket :
PVC,LSZH,PE
Description

4-144 Cores Loose Tube Unarmoured in/out Dielectric Fiber Optic Cable

These cables are constructed with a central tube filled with water blocking jelly, water blocking tape
over the tube giving it excellent water and moisture resistance. A corrugated steel armouring and two
steel wires strengthening with in the outer PE sheath give this cable excellent tensile strength,
mechanical and environmental protection.

They have small diameter, light weight and installation friendly since they come in a single tube with
loose tube fiber count up to 12 fibers. Their compact construction protect the loose tube from shrinking,
the armour makes it crush, rodent and impact resistant, the water proofing tape and jelly protects it from
water and moisture, the outer PE sheath gives it ultraviolet protection.

This cable is suitable for outdoor distribution through ducts, conduits or aerial pipe lines. They come in
larger delivery length, so can also be used in long distance communication system, service drop cables,
building interconnections.

Dielectric Fiber Optic Cable Loose Tube Unarmoured In / Out 4-144 Cores ISO9001 Ceritified

Complied With Or Exceeds Standard
. ITU-T G652.D . ITU-T G651.1 OM1 OM2 OM3 OM4
. ITU-T G657.A . IEC60793-2-10 type A1a.1/A1b OM1/OM2
. IEC60793-2-10 type A1a.2 OM3 . IEC60793-2-10 type A1a.3 OM4
. ISO/IEC 11801 , ISO/IEC 24702 . IEEE 802.3z Gigabit Ethernet
. ANSI/TIA/EIA 568C.3 . ROHS Compliant Directive 2011/65/EU(ROHS2.0)

Mechanical & Environmental Characteristics
ITEM Value
Max. Tensile Load (Short Term) 3000N
Max. Tensile Load (Long Term) 1000N
Max. Crush Load (Short Term) 1500N/100mm
Max Crush Load (Long Term) 500N/100mm
UL Fire Rated OFNR
Operating Temperature -20°C to +60°C
Storage Temperature -40°C to +85°C
Sheath Material Standard: PE Optional: LSZH or other

ANSI/TIA/EIA-598-B Standard Fiber Color Code

Fiber Number Fiber Color Fiber Number Fiber Color
Fiber 1 Blue Fiber 7 Red
Fiber 2 Orange Fiber 8 Black
Fiber 3 Green Fiber 9 Yellow
Fiber 4 Brown Fiber 10 Violet
Fiber 5 Slate Fiber 11 Rose
Fiber 6 White Fiber 12 Aqua

Fiber 13 and higher The color code is repeated with added black stripe or dash
Note: Fiber Tube color will be followed with same order.
