Tight Buffered Fiber Optic Cable 2-24 Cores Excellent Strip Force Stability
Tight Buffered Fiber Optic Cable 2-24 Cores Excellent Strip Force Stability
Specifications
Brand Name :
HG or OEM
Model Number :
GJPFJV
Certification :
ISO9001
Place of Origin :
China
MOQ :
2KM
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
2000KM Per Day
Delivery Time :
5-7 working days
Packaging Details :
4KM/Drum
name :
Indoor 2-24 Cores Distribution Tight Buffer Fiber Optic Cable
Model NO. :
GJPFJV
Sheath Material :
Length According to Requirement Fiber Cores
Cores :
2-24 Cores
Warranty :
2Years
Outer Jacket :
PVC,LSZH
Description

Indoor 2-24 Cores Distribution Tight Buffer Fiber Optic Cable

These cables are used as indoor distribution cables due to ease of their termination and connection.
The installer can recognize saving from lower cost of termination of Tight buffer cables.

They have high moisture resistance and can be routed across multiple bends. Each fiber is mechanically
reinforced with two successive sheaths of 400µm and 900µm which enables direct termination of connectors.
Excellent strip force stability, ber geometrical dimension and transmission performance meets the customer
demand. Available in PVC, LSZH, Plenum outer sheath and tight buffer: 900µm, 600µm. The cable is specially
designed for indoor applications like floor distribution, interconnection and equipment connection.

Tight Buffered Fiber Optic Cable 2-24 Cores Excellent Strip Force Stability

Complied With Or Exceeds Standard
. ITU-T G652.D . ITU-T G651.1 OM1 OM2 OM3 OM4
. ITU-T G657.A . IEC60793-2-10 type A1a.1/A1b OM1/OM2
. IEC60793-2-10 type A1a.2 OM3 . IEC60793-2-10 type A1a.3 OM4
. ISO/IEC 11801 , ISO/IEC 24702 . IEEE 802.3z Gigabit Ethernet
. ANSI/TIA/EIA 568C.3 . ROHS Compliant Directive 2011/65/EU(ROHS2.0)

Mechanical & Environmental Characteristics

ITEM Value
Max. Tensile Load (Short Term) 1500N
Max. Tensile Load (Long Term) 600N
Max. Crush Load (Short Term) 2000N/100mm
Max Crush Load (Long Term) 1000N/100mm
UL Fire Rated OFNR
Operating Temperature -20°C to +60°C
Storage Temperature -40°C to +85°C
Sheath Material Standard: PVC Optional: LSZH, PE or other

ANSI/TIA/EIA-598-B Standard Fiber Color Code

Fiber Number Fiber Color Fiber Number Fiber Color
Fiber 1 Blue Fiber 7 Red
Fiber 2 Orange Fiber 8 Black
Fiber 3 Green Fiber 9 Yellow
Fiber 4 Brown Fiber 10 Violet
Fiber 5 Slate Fiber 11 Rose
Fiber 6 White Fiber 12 Aqua

Fiber 13 and higher The color code is repeated with added black stripe or dash
Note: Fiber Tube color will be followed with same order.
