Light Weight FTTH Drop Cable , Fiber Optic Ethernet Cable 2 Cores Armoured
Light Weight FTTH Drop Cable , Fiber Optic Ethernet Cable 2 Cores Armoured
Specifications
Brand Name :
HG or OEM
Model Number :
GJYXFCH
Certification :
ISO9001
Place of Origin :
China
MOQ :
2KM
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
2000KM Per Day
Delivery Time :
5-7 working days
Packaging Details :
4KM/Drum
name :
FTTH Drop Cable
Model NO. :
GJYXFCH
Sheath Material :
Length According to Requirement Fiber Cores
Cores :
2Cores
Warranty :
2Years
Outer Jacket :
PVC,LSZH
Description

2 Cores Armoured Fiber Optic Drop Cable GJYXFCH FTTH Drop Cable

Two core flat drop cable for fiber To The Home (FTTH) application, the cable is constructed with two
single mode fibers protected by dielectric strength member made of steel wire strength member and
LSZH outer jacket for ultraviolet light protection and outdoor use.

It is very light in construction and easy to install, generally used for connecting Main distribution frame
to consolidation point in home, apartment or offices. Industry standard connectors can be used for direct
termination because of standard 250µm fiber size.

Light Weight FTTH Drop Cable , Fiber Optic Ethernet Cable 2 Cores Armoured

Complied With Or Exceeds Standard
. ITU-T G652.D . ITU-T G651.1 OM1 OM2 OM3 OM4
. ITU-T G657.A . IEC60793-2-10 type A1a.1/A1b OM1/OM2
. IEC60793-2-10 type A1a.2 OM3 . IEC60793-2-10 type A1a.3 OM4
. ISO/IEC 11801 , ISO/IEC 24702 . IEEE 802.3z Gigabit Ethernet
. ANSI/TIA/EIA 568C.3 . ROHS Compliant Directive 2011/65/EU(ROHS2.0)

Mechanical & Environmental Characteristics
DESCRIPTION CABLE SPECIFICATION
G652D G657A
Cladding non-circularity <1.0% ≤0.7%
Mode eld diameter @ 1310nm 8.7~9.5µm 8.4~9.2µm
Cladding diameter 125.0+1.0µm 125.0+0.7µm
Core concentricity error <0.6µm <0.5µm
Primary coating diameter 245±7µm 245±5µm
Coating-cladding concentricity error ≤12.0up
fiber bend radius >4m
Proof level >1.5% strain
Fiber type G652D OR G657A
Tensile load 80N
Temperature -20~60°C

ANSI/TIA/EIA-598-B Standard Fiber Color Code

Fiber Number Fiber Color Fiber Number Fiber Color
Fiber 1 Blue Fiber 7 Red
Fiber 2 Orange Fiber 8 Black
Fiber 3 Green Fiber 9 Yellow
Fiber 4 Brown Fiber 10 Violet
Fiber 5 Slate Fiber 11 Rose
Fiber 6 White Fiber 12 Aqua

Fiber 13 and higher The color code is repeated with added black stripe or dash
Note: Fiber Tube color will be followed with same order.
