Indoor 6 Cores Fiber Optic Splitter Box 6 Ports For Connected FTTH Drop Inside Cables
Indoor 6 Cores Fiber Optic Splitter Box 6 Ports For Connected FTTH Drop Inside Cables
Indoor 6 Cores Fiber Optic Splitter Box 6 Ports For Connected FTTH Drop Inside Cables
Indoor 6 Cores Fiber Optic Splitter Box 6 Ports For Connected FTTH Drop Inside Cables
Indoor 6 Cores Fiber Optic Splitter Box 6 Ports For Connected FTTH Drop Inside Cables
Indoor 6 Cores Fiber Optic Splitter Box 6 Ports For Connected FTTH Drop Inside Cables
Indoor 6 Cores Fiber Optic Splitter Box 6 Ports For Connected FTTH Drop Inside Cables
Indoor 6 Cores Fiber Optic Splitter Box 6 Ports For Connected FTTH Drop Inside Cables
Specifications
Brand Name :
HG or OEM
Model Number :
FDB-106C
Certification :
CE, ROHS, ISO9001
Place of Origin :
China
MOQ :
10pcs
Delivery Time :
5-7 days
Packaging Details :
1pc/Box
name :
fiber optic splitter box
Model :
FTB-106C
Material :
ABS
Type :
Distribution Box 4ports
Warranty :
5 years
Color :
White
Description

Indoor 6 Cores Fiber Optic Splitter Box 6 Ports FTTH Splitter Box

Introduction:

FTTH Mini type terminal box is light and compact, especially suitable for protective connection of fiber cables and pigtails in FTTH. Widely used in the end termination of residential buildings and villas, to fix and splice with pigtails; Can be installed on the wall; May adapt variety of optical connection styles; Optical fiber can be managed effectively. Available for 1*2/1*4 PLC Splitter, 1x6 FBT Splitter, also can be used to splicing 6fibers max.

Features:

1.1 FTTH network and CATV system application.

1.2 Available for 1*2/1*4 PLC Splitter. Design to protect PLC splitter.

1.3 Suit for both Outdoor & Indoor. IP65 Grade.

1.4 Waterproof, Anti-UV, Ultra violet resistant and rainfall resistant.

1.4 Light weight, small cubage, small installation size,realiable sealing.

1.5 Could be connected FTTH Drop cables inside. Design the splicing place for Mechanical Splice

1.6 The base and cover of the box adopts “self-clip” &”screw-clip” two times lock method, which is better to use in outdoor for high sealing and waterproof.

Cable port:

Could be connected 1 inlet ports, 6 outlet ports.

Cable diameter(mm): φ7~φ10

Main Technical Indexes:

2.1 Environmental Temperature:-40°C~60°C;

2.2 Max capacity: 6 fibers;

2.3 Application for outdoor, IP65 grade

2.4 Material: High impact plastic.

Dimension:

Model Capacity Size(mm) Weight (kg)
FTB-106C ports 210(W)X140(H)x40(D)

0.45

Indoor 6 Cores Fiber Optic Splitter Box 6 Ports For Connected FTTH Drop Inside Cables

Indoor 6 Cores Fiber Optic Splitter Box 6 Ports For Connected FTTH Drop Inside Cables

Indoor 6 Cores Fiber Optic Splitter Box 6 Ports For Connected FTTH Drop Inside Cables
