MPO-FC Ribbon Single Mode Fiber Patch Cord 12 Cores Return Loss ≥ 60dB
MPO-FC Ribbon Single Mode Fiber Patch Cord 12 Cores Return Loss ≥ 60dB
Specifications
Brand Name :
HG or OEM
Model Number :
12Cores MPO MTP Patch Cord
Certification :
ROHS,ISO9001
Place of Origin :
China
MOQ :
10pcs
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
2000pcs Per Day
Delivery Time :
3-5working days
Packaging Details :
1pc/PE Bag
name :
single mode fiber patch cord
Manufacturer :
Yes
Quality :
Telcordia GR-326-Core, IEC Standard
Fiber Type :
Simplex and Duplex, G652D, G655, anything, SM or MM
Connector type :
SC/FC/LC/ST/MU/DIN/D4/MTRJ/MPO
Samples :
Support
Description

Ribbon Type Singlde MPOemo MTP Patch Cord 12 Cores MPO-FC Fiber Jumper

The MPO MTP fiber patch cable meets RoHS compliant, and all cables are 100% optically tested for insertion loss to ensure high quality, it is very cost-effective for network cabling.

HG also provides a full set of OEM services, such as fiber connector, length, color, fiber grade, specification, material, package etc.

Feature:

(1) Inner: Ceramic Ferrule

(2) Telcordia’s GR-326-Core, IEC Standard

(3) Green Production, RoHS Standard

(4) Excellent Polished and 100% tested.

(5) High stability various environments

(6) Customize order available

Items Details:

Connector Type Performance Level
Standard Elite
Connector Mode Endface IL(dB) RL(dB) IL(dB) RL(dB)
LC/SC/FC/ST SM PC ≤0.2 ≥50 ≤0.15 ≥50
UPC ≤0.2 ≥55 ≤0.15 ≥55
APC ≤0.2 ≥60 ≤0.15 ≥60
MM PC ≤0.2 ≥35 ≤0.15 ≥35
MPO/MTP SM APC ≤0.7 ≥60 ≤0.35 ≥60
MM PC ≤0.5 ≥20 ≤0.35 ≥20
MTRJ SM PC ≤0.5 ≥50 / /
MM PC ≤0.5 ≥35 /

MPO-FC Ribbon Single Mode Fiber Patch Cord 12 Cores Return Loss ≥ 60dB

Available :

Simplex/Duplex patch cord available

Fan-out available

Pigtail available

Various boot(cable) sizes available

FC/LC/SC/ST/MTRJ/MPO connectors available

LSZH and PVC cable

1. Jacket Material:

MPO-FC Ribbon Single Mode Fiber Patch Cord 12 Cores Return Loss ≥ 60dB


2. Customize Cable Length: 0.5M/1M/2M/3M/5M to 100M

3..Packing:

MPO-FC Ribbon Single Mode Fiber Patch Cord 12 Cores Return Loss ≥ 60dB

MPO-FC Ribbon Single Mode Fiber Patch Cord 12 Cores Return Loss ≥ 60dB

MPO-FC Ribbon Single Mode Fiber Patch Cord 12 Cores Return Loss ≥ 60dB

MPO-FC Ribbon Single Mode Fiber Patch Cord 12 Cores Return Loss ≥ 60dB
