Optical WDM Filter Wavelength Division Multiplexer 1x2 Broadband FWDM Module
Optical WDM Filter Wavelength Division Multiplexer 1x2 Broadband FWDM Module
Optical WDM Filter Wavelength Division Multiplexer 1x2 Broadband FWDM Module
Optical WDM Filter Wavelength Division Multiplexer 1x2 Broadband FWDM Module
Optical WDM Filter Wavelength Division Multiplexer 1x2 Broadband FWDM Module
Optical WDM Filter Wavelength Division Multiplexer 1x2 Broadband FWDM Module
Optical WDM Filter Wavelength Division Multiplexer 1x2 Broadband FWDM Module
Optical WDM Filter Wavelength Division Multiplexer 1x2 Broadband FWDM Module
Specifications
Brand Name :
UNIFIBER
Model Number :
FWDM
Certification :
ROHS
Place of Origin :
CHINA
MOQ :
10pcs
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1000pcs/day
Delivery Time :
3-5days
Packaging Details :
Blister Case
Wavelength :
1310/1490/1550nm
Package :
Steel tube,ASB box
Pigtail type :
250um bare fiber,900um loose tube,2.0mm,3.0mm
Connector type :
FC,SC,LC,ST or Customized
Description

1x2 Broadband FWDM Module Optical WDM Filter TX1550/RX 1310 & 1490nm ABS Box Packed

The 1310/1550nm Filter Wavelength Division Multiplexer is based on environmentally stable thin-film filter technology. The devices combine or separate light at different wavelength in a wide wavelength range. They offer very low insertion loss, low polarization dependence, high isolation and excellent environmental stability. High power handling capability can be achieved through unique pigtail processing and high quality AR coating. These components have been extensively used in EDFAs, Raman amplifiers, WDM networks and fiber optical instruments.

Features:

Low Insertion Loss
High channel Isolation
Wide pass band
High reliability and stability
Epoxy free on optical path

Application:

Line monitoring
Telecom munication
Cellular Application
Fiber optical Amplifier
Access Network

Parameter 1310/1550 1510/1550 1625/1585 1640/1620 1600/1580 1450/1550
Wavelength (nm) Type 1 Pass band 1310±40 1500-1521 1620-1630 1640-1670 1600-1670 1430-1510
Reflection band 1550±40 1529-1563 1570-1605 1260-1620 1290-1580 1529-1600
Type 2 Pass band 1550±40 1260-1620
Reflection band 1310±40 1640-1670
Pass insertion loss (dB) <0.8
Reflection insertion loss (dB) <0.6
Pass channel isolation (dB) >30
Reflection isolation (dB) >15
Channel flatness (dB) <0.3
Directivity (dB) >55
Return loss (dB) >50
PDL (dB) <0.1
Wavelength thermal stability (nm/°C) <0.003
Insertion loss thermal stability(dB/"C) <0.005
Power handling (mW) <300
Operating temperature (°C) 0 -+65

Optical WDM Filter Wavelength Division Multiplexer 1x2 Broadband FWDM ModuleOptical WDM Filter Wavelength Division Multiplexer 1x2 Broadband FWDM Module
