Duplex Armored Fiber Patch Cords Singlemode Blue LSZH Jacketed With Customized Length
Duplex Armored Fiber Patch Cords Singlemode Blue LSZH Jacketed With Customized Length
Duplex Armored Fiber Patch Cords Singlemode Blue LSZH Jacketed With Customized Length
Duplex Armored Fiber Patch Cords Singlemode Blue LSZH Jacketed With Customized Length
Specifications
Brand Name :
UNIFIBER-OEM
Model Number :
E2000
Certification :
ROHS
Place of Origin :
CHINA
MOQ :
10PCS
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
10000pcs/day
Delivery Time :
3-5days
Packaging Details :
PE bag
Connector type :
E2000/MTRJ/MU/FC/SC/LC/ST
Cable diameter :
2.0/3.0mm
Fiber Count :
Simplex or Duplex
Cable jacket :
PVC/LSZH
Fiber :
SM or MM
Color :
Yellow/Orange/Gray
Description

E2000-LC duplex armored fiber patch cords singlemode blue LSZH jacketed with customized length

E2000 fiber optic patch cord also called e2000 fiber optic jumper/patch cable, includes e2000 single mode or multimode,simplex or duplex fiber optic patch cord with 9/125um,50/125um,62.5/125um indoor fiber optic cable. the usual polishing type is pc,upc and apc.E2000 range of standard patch cords are suitable for telecom, datacom, data center and some critical applications.

Application:
Data Centre

CATV
LAN and WAN
FTTX

Telecommunication networks
Broadband network

Feature:
E2000 and E2000 APC optic connectors with metal shutter

Available as hybrid patch cords with different connector types including FC, LC, SC or ST
Low smoke zero halogen (LSZH) jacket color coded to identify the optical fiber type

Available in different fiber types including OS1/OS2 - G.652D or G657A1, G.657A2, OM1, OM2, OM3 or OM4
Available in standard and custom lengths
REACH, RoHS & SvHC materials compliant.

Parameters

Item SingleMode MultiMode
Insertion loss ≤0.2dB ≤0.3dB
Return loss PC≥50dB, APC≥55dB, UPC≥60dB
Insert-pull test 1000 times
Repeatability ≤0.1
Tensile strength ≥10kg
Operating temperature -40℃~ +85℃
Ceramic ferrule spec 125.5um concentricity deviations:≤1μm 127um concentricity deviations:≤3μm
Suitable fiber 9/125μm 50/125μm, 62.5/125μm
