LC fiber optic adapter Fiber Optic Couplers SM/MM/OM3/OM4/OM5 With Metal Shutter,dust protectection and eye protection
LC fiber optic adapter Fiber Optic Couplers SM/MM/OM3/OM4/OM5 With Metal Shutter,dust protectection and eye protection
LC fiber optic adapter Fiber Optic Couplers SM/MM/OM3/OM4/OM5 With Metal Shutter,dust protectection and eye protection
LC fiber optic adapter Fiber Optic Couplers SM/MM/OM3/OM4/OM5 With Metal Shutter,dust protectection and eye protection
LC fiber optic adapter Fiber Optic Couplers SM/MM/OM3/OM4/OM5 With Metal Shutter,dust protectection and eye protection
LC fiber optic adapter Fiber Optic Couplers SM/MM/OM3/OM4/OM5 With Metal Shutter,dust protectection and eye protection
LC fiber optic adapter Fiber Optic Couplers SM/MM/OM3/OM4/OM5 With Metal Shutter,dust protectection and eye protection
LC fiber optic adapter Fiber Optic Couplers SM/MM/OM3/OM4/OM5 With Metal Shutter,dust protectection and eye protection
Specifications
Brand Name :
UNIFIBER-OEM
Certification :
ROHS
Place of Origin :
CHINA
MOQ :
100pcs
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
10000pcs/day
Delivery Time :
3-5days
Packaging Details :
blister case
Connector type :
LC
Mode :
SM/MM/OM3/OM4/OM5
Polish type :
PC/APC/UPC
Color :
Green, blue, Red, gray, Beige or Customized
IL :
≤0.2dB
Application :
Network, Telecommunication/Fiber Optic CATV/Multimedia
Description

LC fiber optic adapter Fiber Optic Couplers SM/MM/OM3/OM4/OM5 With Metal Shutter,dust protectection and eye protection

Features
Low insertion loss & High return loss
High Reliability & Good interchangeability
Low environmental sensitivity
​
Application
Telecom network
Ethernet network
Optical communication equipment

LC Quad Fiber optic Adapter with internal shutter-Full flange is a one-piece design adapter. The shutter is 100% automatic and requires no physical handling of the shutter door. You can actuate this integrated, retractable shutter inside the adapter body by inserting the LC connector into the adapter. The shutter automatically opens as you insert the LC connector, and closes as you extract it. Due to the special design of the shutter, it will not touch the ferrule end face when you insert a connector, thus preventing end face damage. The internal shutter prevents eye exposure to lasers and provides protection from dust and other contaminants.

Specifications

Test item (SM-9/125) UPC (SM-9/125) APC MM PC
Insertion Loss ≤0.2dB(Standard Grade); ≤0.1dB(Premium Grade);
Return Loss ≥50 dB ≥60 dB ≥35 dB
Durability (1000 Mating) 0.1dB Max.
Withdrawal force(g/f) 2.0N ~ 5.9N (200gf ~ 600gf)
Storage Temp(℃) -40~+85

LC fiber optic adapter Fiber Optic Couplers SM/MM/OM3/OM4/OM5 With Metal Shutter,dust protectection and eye protectionLC fiber optic adapter Fiber Optic Couplers SM/MM/OM3/OM4/OM5 With Metal Shutter,dust protectection and eye protectionLC fiber optic adapter Fiber Optic Couplers SM/MM/OM3/OM4/OM5 With Metal Shutter,dust protectection and eye protection
