100G 200G DWDM Wavelength Division Multiplexer 4 8 12 16 20 Channel
100G 200G DWDM Wavelength Division Multiplexer 4 8 12 16 20 Channel
100G 200G DWDM Wavelength Division Multiplexer 4 8 12 16 20 Channel
100G 200G DWDM Wavelength Division Multiplexer 4 8 12 16 20 Channel
100G 200G DWDM Wavelength Division Multiplexer 4 8 12 16 20 Channel
100G 200G DWDM Wavelength Division Multiplexer 4 8 12 16 20 Channel
Specifications
Brand Name :
UNIFIBER-OEM
Model Number :
100G/200G Ultra Compact DWDM
Certification :
ROHS
Place of Origin :
CHINA
MOQ :
10pcs
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
500pcs/day
Delivery Time :
3~5 business days
Packaging Details :
Carton box
Product :
100G/200G Ultra Compact DWDM Mux/Demux
Channels :
4/8/12/16/20 Channel
Dimension :
Ultra compact
Pigail :
900um Loose Tube
Fiber :
Corning G.657 A1 fiber
Application :
DWDM networks
Description

ultra-compact DWDM is based on TFF platform. A series TFFs are attached to a glass or metal base. Multiple wavelengths incident to the filters at certain angle with one wavelength pass through while all other bands of wavelength are reflected. To make it ultra-compact, folding mirrors are used and light path is zigzag form. The integrated optical and mechanical components are then tightly packaged. The function of such DWDM device is to combine multiple wavelengths into single fiber or send different wavelengths to separate fibers. The device works uni- or bidirectional. Multiple fibers are coming out from the same side of device to make the fiber management easier.

Features

Ultra-compact

Based on TFF technology

Ultra-low Insertion loss

Stable at wide range of operating temperatures

One side fiber feedthrough


Applications

DWDM networks,

NG-PON2, 5G xHaul, Phased Array Antennas, Airborne/Satellite Communications

Parameters

Unit

4 Channels

8 Channels

 12 Channels

16 Channels

20 Channels
Insertion Loss dB ≤1.3 ≤1.5 ≤1.8 ≤2.0 ≤2.6
Ripple dB ≤0.5 ≤0.5 ≤0.5 ≤0.5 ≤0.5
Polarization Dependent Loss dB ≤0.3 ≤0.3 ≤0.3 ≤0.3 ≤0.3
Dimension mm 25x12.8x6.5 30x16x6.5 39x24x6.5 39x24x6.5 39x27x6.5
Channel Center Wavelengths nm ITU
Channel Spacing nm

100G:0.8

200G:1.6
Channel Passband nm

100G: λc ± 0.11(Min.)

200G: λc ± 0.25(Min.)
Isolation-Adjacent dB ≥30
Isolation-Non-adjacent dB ≥ 40
Return Loss dB ≥45
Directivity dB ≥50
