1470nm~1610nm 8 Channel CWDM Mux Demux LC UPC Passive Optical Module
1470nm~1610nm 8 Channel CWDM Mux Demux LC UPC Passive Optical Module
1470nm~1610nm 8 Channel CWDM Mux Demux LC UPC Passive Optical Module
1470nm~1610nm 8 Channel CWDM Mux Demux LC UPC Passive Optical Module
1470nm~1610nm 8 Channel CWDM Mux Demux LC UPC Passive Optical Module
1470nm~1610nm 8 Channel CWDM Mux Demux LC UPC Passive Optical Module
Specifications
Brand Name :
UNIFIBER-OEM
Model Number :
8 Channel CWDM Mux Demux
Certification :
ROHS
Place of Origin :
CHINA
MOQ :
10pcs
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
500pcs/day
Delivery Time :
5~7 Business days
Packaging Details :
Carton Box
Operating Wavelength :
1470nm~1610nm 8 Channel CWDM Mux Demux Passive Optical Module
No of Channel :
8 Channel(1470nm~1610nm)
Package :
ABS Module
Connector :
LC/UPC
Fiber type :
900um loose tube
Configuration :
Mux or Demux
Channel Spacing :
20nm
Description

1270nm~1610nm 4/6/8/16 Channel CWDM Mux Demux Passive Optical Module is an excellent choice for increasing bandwidth capacity while keeping costs down. based on standard Thin Film Filter (TFF) technology with a proprietary packaging, Our CWDM MUX DEMUX are perfectly suited to transport PDH, SDH / SONET, ETHERNET services over WWDM, CWDM and DWDM in optical metro edge and access networks.

APPLICATION
CWDM Channels Add/Drop
CWDM
CATV Fiber Optical Links
Accessing LAN Networks
Short-Distance Communications

FEATURES
High Stability & Reliability

Low Insertion Loss
Excellent Channel Isolation
Low Cost

Parameters:

Parameter 4 Channel 8 Channel 18 Channel
Mux Demux Mux Demux Mux Demux
Channel Wavelength (nm) 1270~1610
Center wavelength Accuracy (nm) ±0.5
Channel Spacing (nm) 20
Channel Passband (@-0.5dB bandwidth (nm) >13
Insertion Loss (dB) ≤1.2 ≤1.5 ≤3.0
Channel Uniformity (dB) ≤0.5 ≤1.0 ≤1.5
Channel Ripple (dB) 0.3
Isolation (dB) Adjacent N/A >30 N/A >30 N/A >30
Non-adjacent N/A >40 N/A >40 N/A >40
Inertion Loss Temperature Sensitivity (dB/°C) <0.005
Wavelength Temperature Shifting (nm/°C) <0.002
Polarization Dependent Loss (dB) <0.1
Polarization Mode Dispersion <0.1
Directivity (dB) >50
Return Loss (dB) >45
Maximum Power Handling (mW) 500
Opterating Temperature (°C) -5~+75
Storage Temperature (°C) -40~85
Package dimension (mm) L100 x W80 x H10 or L140xW100xH15

Above specification are for device without connector.

Ordering Information

Configuration Number of Channels 1st Channel Fiber Type Fiber Length In/Out Connector

M=Mux D=Demux

O=OADM

04=4 Channel

08=8 Channel

16=16 Channel

18=18 Channel
N=N Channel

……

27=1270nm
47=1470nm
49=1490nm

……
61=1610nm
SS=special

1=Bare fiber
2=900um
Loose tube
3=2mm Cable
4=3mm Cable		 1=1m
2=2m
S=Specify

0=None
1=FC/APC
2=FC/PC
3=SC/APC
4=SC/PC
5=LC

……
1470nm~1610nm 8 Channel CWDM Mux Demux LC UPC Passive Optical Module
