SCUPC Armoured Fiber Optic Cable Patch Cord With Lateral Pressure Protected
SCUPC Armoured Fiber Optic Cable Patch Cord With Lateral Pressure Protected
SCUPC Armoured Fiber Optic Cable Patch Cord With Lateral Pressure Protected
SCUPC Armoured Fiber Optic Cable Patch Cord With Lateral Pressure Protected
SCUPC Armoured Fiber Optic Cable Patch Cord With Lateral Pressure Protected
SCUPC Armoured Fiber Optic Cable Patch Cord With Lateral Pressure Protected
SCUPC Armoured Fiber Optic Cable Patch Cord With Lateral Pressure Protected
SCUPC Armoured Fiber Optic Cable Patch Cord With Lateral Pressure Protected
Specifications
Brand Name :
hanxin or OEM
Model Number :
SCUPC
Certification :
ROHS, ISO9001
Place of Origin :
Shenzhen ,China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
5000 pcs per week
Delivery Time :
3-7 working days
Packaging Details :
PP bag and carton
Connector type :
SCUPC
Cable Type :
Armoured
Connector color :
Blue
Cable color :
Blue
Cable jacket :
PVC/LSZH
Application :
FTTX PON CATV
Length :
1M,2M,3M,Customized
Quality control :
100% test before shipping
Description

SCUPC Armoured Fiber Optic Cable Patch Cord With Lateral Pressure Protected

The biggest difference between armoured patchcords with other patchcords is not easy to be damaged, because of a small stainless steel casing out of the fiber. Armoured patchcords use flame-retardant PVC. This design can make project convenient and lengthen the fiber life.

Application:

optical fiber sensor, telecommunication equipment

optical fiber communication system, LAN

TV, communication allocation, National defense.

Test equipments, Active optic device

FTTH

Features:

High tensile strength

Lateral pressure protected

Defense rat

Soft, strong adaptability

project convenient

low insertion loss, high return loss

Realize the active link of optic fiber transmission

Specifications:

SM MM
connector type FC/PC FC/UPC FC/APC FC/PC
SC/PC SC/UPC SC/APC SC/PC
ST/PC ST/UPC ST/PC
LC/PC LC/UPC LC/PC
return loss ≥45dB ≥50dB ≥60dB ≥35 dB
insertion loss ≤0.2dB
operating temperature -40℃~+80℃
repeatability ≤0.1dB
interchangeability ≤0.2dB
Plug times 1000 times
tensile strength >100N

SCUPC Armoured Fiber Optic Cable Patch Cord With Lateral Pressure Protected

SCUPC Armoured Fiber Optic Cable Patch Cord With Lateral Pressure Protected

Packaging

SCUPC Armoured Fiber Optic Cable Patch Cord With Lateral Pressure Protected
