SC / UPC 2.0mm 1M ABS Module Fiber Optic Splitter G657A 1x2 PLC Singlemode
SC / UPC 2.0mm 1M ABS Module Fiber Optic Splitter G657A 1x2 PLC Singlemode
SC / UPC 2.0mm 1M ABS Module Fiber Optic Splitter G657A 1x2 PLC Singlemode
SC / UPC 2.0mm 1M ABS Module Fiber Optic Splitter G657A 1x2 PLC Singlemode
SC / UPC 2.0mm 1M ABS Module Fiber Optic Splitter G657A 1x2 PLC Singlemode
SC / UPC 2.0mm 1M ABS Module Fiber Optic Splitter G657A 1x2 PLC Singlemode
Specifications
Brand Name :
DAMU
Model Number :
ABS 1*2U
Certification :
CE
Place of Origin :
CHINA
MOQ :
2pcs
Supply Ability :
20000pcs/day
Packaging Details :
blister packing,outside carton
material :
ABS BOX
connector :
SCUPC
fiber :
G675A OR G625D
Length :
1.0m (±0.1) or customer specified
packing :
blister or box
fiber dia :
2.0mm
Description

1*2 SC/UPC 2.0mm 1M SM ABS Module BOX type fiber optic splitter G657A 1x2 PLC Singlemode

Planar lightwave circuit (PLC) splitter is a type of optical power management device that is fabricated using silica optical waveguide technology to distribute optical signals from Central Office (CO) to multiple premise locations.

Pigtailed ABS splitter is most commonly used in the PON networks. It provides the complete protection for inner optical components and cable, as well as designed for the convenient and reliable installation, but its volume is relatively large. It's mainly used for various connection and distribution products(outdoor fiber distribution box) or network cabinets.
Package Style
ABS Module
Configuration Type
1 x 2
Fiber Grade
G.657A1
Fiber Mode
Singlemode
Connector Type
SC/UPC
Split Ratio
50/50
Input/Output Fiber Diameter
2.0mm
Input/Output Fiber Length
1.5m
Insertion Loss
≤ 4.0dB
Return Loss
≥ 55dB
Loss Uniformity
≤ 0.4dB
Directivity
≥ 55dB
Polarization Dependent Loss
≤ 0.2dB
Temperature Dependent Loss
≤ 0.5dB
Wavelength Dependent Loss
≤ 0.3dB
Operating Bandwidth
1260~1650nm
Operating Temperature
-40 to 85°C
(-40 to 185°F)
Storage Temperature
-40 to 85°C
(-40 to 185°F)

SC / UPC 2.0mm 1M ABS Module Fiber Optic Splitter G657A 1x2 PLC SinglemodeSC / UPC 2.0mm 1M ABS Module Fiber Optic Splitter G657A 1x2 PLC SinglemodeSC / UPC 2.0mm 1M ABS Module Fiber Optic Splitter G657A 1x2 PLC Singlemode
