2Core optical fiber drop cable 10m 20m 30m 100m Gjyxfch flat drop fiber cable
2Core optical fiber drop cable 10m 20m 30m 100m Gjyxfch flat drop fiber cable
2Core optical fiber drop cable 10m 20m 30m 100m Gjyxfch flat drop fiber cable
2Core optical fiber drop cable 10m 20m 30m 100m Gjyxfch flat drop fiber cable
Specifications
Brand Name :
Sea dragon
Certification :
ISO9001 / CE / RoHS
Place of Origin :
Hebei china
MOQ :
2000 Meters
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
10000 Kilometer/Kilometers per Month
Packaging Details :
wooden reel.then packed ftth cable into cartons.
Place of Origin: :
Hebei, China
Brand: :
Wolong
Model: :
Incoming cable
Number of conductors: :
2
Product name: :
Sc Apc 50 m fiber optic patch cord
Insertion loss: :
<0.2dB (typical value), 0.3dB (maximum)
Certification: :
ISO9001: 2015
Length: :
100 million
Cable structure: :
3 * 2 butterfly flat type, 5 * 2mm aerial self-supporting type,
Guarantee: :
3 years
Wavelength: :
1310nm / 1490nm / 1550nm
Return loss: :
> 35dB
Description

Ftth Indoor Optical Fiber Drop Cable Single Core 2 Core Flat Drop 10m 20m 30m 100m Gjyxfch G657 Sc Apc 50 M Fiber Optic

Product Structure

GJYXFCH cable is a kind of indoor and outdoor dual-purpose optical cable. Its structure is butterfly-shaped, glass fiber is the reinforced part, and the self-supporting cable is low-smoke and halogen-free sheath. For GJYXFCH drop-in cable jumper, according to customer requirements, there are 10 m 20 m 50 m 100 m etc.


image:

2Core optical fiber drop cable 10m 20m 30m 100m Gjyxfch flat drop fiber cable

Feature:

1. Special low-band sensitivity fiber with high bonding bandwidth and excellent communication transmission performance;

2, Two parallel strong members ensure good compressive performance and protect fibers;

3. Simple structure, light weight and strong practicability;

4. Novel flute design, easy to peel and splice, simplifying installation and maintenance;

5.A single steel wire is used as an additional strength component to ensure good tensile strength performance.

Optical properties

place of origin:

 Hebei, China

Brand:

 Wolong

Model:

 Incoming line

Number of conductors:

 2

product name:

 Sc Apc 50 m fiber optic patch cord

Insertion loss:

 <0.2dB (typical value), 0.3dB (maximum)

Certification:

 ISO9001:2015

Length:

 100000000

Cable structure:

 3 * 2 butterfly flat type, 5 * 2mm antenna self supporting type,

Guarantee:

 3 years

Wavelength:

 1310nm / 1490nm / 1550nm

Return loss:

 > 35dB
Standard: Telcordia GR-326. Color
Clean end face sealing gasket: 100% clean, no dust, no water, no scratches

FAQ:

Question 1: Are you a trading company or a manufacturer?
Answer: We have passed the factory verification of SGS

Question 2: Do you provide OEM service?
A: Yes, we can print your logo or label on the product or packaging box.

Question 3: Can you provide free samples?
Answer: Some low-value samples can be provided to you for free, but you need to pay for the shipping cost.

Question 4: How to ensure quality?
Answer: On the basis of our perfect quality management system, all our products are 100% tested before leaving the factory.

Q5: What is your delivery time?
Answer: Usually, samples: 3~5 working days. Formal orders: 7-10 working days.

Question 6: What are your payment terms?
Answer: We accept wire transfer, Western Union, MoneyGram, Paypal.
For samples: 100% payment. Formal orders: 30% as deposit and 70% balance to be paid before shipment.
