Generic Compatible 100G QSFP28 MMF LR4 SFP Fiber Optic Transceiver 60km
Generic Compatible 100G QSFP28 MMF LR4 SFP Fiber Optic Transceiver 60km
Generic Compatible 100G QSFP28 MMF LR4 SFP Fiber Optic Transceiver 60km
Generic Compatible 100G QSFP28 MMF LR4 SFP Fiber Optic Transceiver 60km
Specifications
Brand Name :
YT
Model Number :
YT-FE2110A-25
Certification :
ISO, SGS, ROHS
Place of Origin :
china shenzhen
MOQ :
10 pcs
Price :
Negotiation
Payment Terms :
XTransfer T/T, Western Union, PayPal
Supply Ability :
5000 pcs/Month
Delivery Time :
3-7days
Product Name :
Fiber Optic Transceiver
Wavelength :
850nm
Media :
MMF
Max Data Rate :
103.1 Gbps
Transmitter Type :
VCSEL 850nm
Power Supply :
Single +3.3V
Description

Generic Compatible 100G QSFP28 MMF LR4 60km Fiber Optical Transceiver

The Hangalaxy 100Gb/s optical transceiver is designed for use in 100 Gigabit Ethernet links on up to 10km of single mode fiber. It is also qualified for use in Mellanox InfiniBand EDR end-to-end systems. The fiber optical transceiver is compliant with the QSFP28 MSA, IEEE 802.3ba 100GBASE-LR4 and IEEE 802.3bm CAUI-4. Digital diagnostic functions are available via the I2 C interface, as specified by the QSFP28 MSA. The module converts 4 input channels of 25Gb/s electrical data to 4 channels of LAN WDM optical signals and then multiplexes them into a single channel for 100Gb/s optical transmission. Reversely, on the receiver side the module de-multiplexes a 100Gb/s optical LAN WDM input into 4 optical signals and then converts them to 4 output channels of electrical data.

Features

(1) Hot pluggable QSFP28 MSA form factor;
(2) Compliant to IEEE 802.3ba 100GBASE-LR4;
(3) Supports 103.1Gb/s aggregate bit rate;
(4) Up to 10km reach for G.652 SMF;
(5) Single +3.3V power supply;
(6) Operating case temperature: 0~70oC;
(7) Transmitter: cooled 4x25Gb/s LAN WDM DFB TOSA (1295.56, 1300.05, 1304.58, 1309.14nm);
(8) Receiver: 4x25Gb/s PIN ROSA;
(9) 4x25G electrical interface (OIF CEI-28G-VSR);
(10) Maximum power consumption 4.0W;
(11) Duplex LC receptacle;
(12) RoHS-6 compliant.

Applications


(1) 100GBASE-LR4 Ethernet Links;
(2) Infiniband QDR and DDR interconnects;
(3) Datacenter and Enterprise networking.

Technical Parameter

Pin Name Description Plug Sequence Notes
1 GND Ground 1
2 Tx2n Transmitter Inverted Data Input 3
3 Tx2p Transmitter Non-Inverted Data Input 3
4 GND Ground 1
5 Tx4n Transmitter Inverted Data Input 3
6 Tx4p Transmitter Non-Inverted Data Input 3
7 GND Ground 1
8 ModSelL Module Select 3
9 ResetL Module Reset 3
10 Vcc Rx +3.3 V Power supply receiver 2
11 SCL 2-wire serial interface clock 3
12 SDA 2-wire serial interface data 3
13 GND Ground 1
14 Rx3p Receiver Non-Inverted Data Output 3
15 Rx3n Receiver Inverted Data Output 3
16 GND Ground 1
17 Rx1p Receiver Non-Inverted Data Output 3
18 Rx1n Receiver Inverted Data Output 3
19 GND Ground 1
20 GND Ground 1
21 Rx2n Receiver Inverted Data Output 3
22 Rx2p Receiver Non-Inverted Data Output 3
23 GND Ground 1
24 Rx4n Receiver Inverted Data Output 3
25 Rx4p Receiver Non-Inverted Data Output 3
26 GND Ground 1
27 ModPrsL Module Present 3
28 IntL Interrupt 3
29 Vcc Tx +3.3 V Power supply transmitter 2
30 Vcc1 +3.3 V Power Supply 2
31 LPMode Low Power Mode 3
32 GND Ground 1
33 Tx3p Transmitter Non-Inverted Data Input 3
34 Tx3n Transmitter Inverted Data Input 3
35 GND Ground 1
36 Tx1p Transmitter Non-Inverted Data Input 3
37 Tx1n Transmitter Inverted Data Input 3
38 GND Ground 1

Notes


1. Due to measurement accuracy of different single mode fibers, there could be an additional +/-1 dB fluctuation, or a +/- 3 dB total accuracy.
