Figure 8 GYTC8S Self Supporting Fiber Optic Cable Armored 72 Core Fiber Optic Cables
Figure 8 GYTC8S Self Supporting Fiber Optic Cable Armored 72 Core Fiber Optic Cables
Figure 8 GYTC8S Self Supporting Fiber Optic Cable Armored 72 Core Fiber Optic Cables
Figure 8 GYTC8S Self Supporting Fiber Optic Cable Armored 72 Core Fiber Optic Cables
Specifications
Place of Origin :
china shenzhen
Brand Name :
YT
Certification :
ISO, SGS, ROHS
MOQ :
10 pcs
Price :
Negotiation
Delivery Time :
3-7days
Payment Terms :
XTransfer T/T, Western Union, PayPal
Supply Ability :
5000 pcs/Month
Product name :
Armored Fiber Optic Cable
Fiber Type :
G652D Or As Your Request
Fiber Count :
2-288core
Strength Tape :
APL
Application :
Aerial / Duct / Direct Burial
Installation :
Self- Supporting Aerial
Description

72core Figure 8 GYTC8S Self-Supporting Armored Fiber Optic Cable

Description:

The fibers are placed in a loose tube made of high modulus plastic. The tubes are filled with a water-resistant filling compound. A steel wire locates in the center of core as a metallic strength member. The tubes (and fillers) are stranded around the strength member into a compact and circular cable core. After PSP is applied around the cable core, this part of cable accompanied with the stranded wires as the supporting part are completed with a polyethylene (PE) sheath to be figure 8 structure. This kind of cable is specifically applied for self-supporting aerial installation.

Cable Mechanical Characteristic:

Cable type Diameter (mm) Weight (kg/km) Tensile strength
Long/short term (N)		 Crush Resistance Long/Short Term(N/100mm) Bending radius
Dynamic/static (mm)		 Storage temperature ( ℃ )
GYTC8S-2~36 8.6*15 140 600/1500 300/1000 20D/10D -20~+70
GYTC8S-38~72 10.5*16.9 190
GYTC8S-74~96 12*19 250
GYTC8S-98~120 13*20 270
GYTC8S-122~144 15*22 305

Mechanical requirements and methods of fiber cable:

Tensile strength 10935N, conform to IEC 794-1-E1,While Fiber Strain≤0.33%
Crush 2200N/100mm, conform to IEC 794-1-E3
Impact Conform to IEC 794-1-E4
Repeated bending Conform to IEC 794-1-E6
Torsion Conform to IEC 794-1-E7
Flexing Conform to IEC 794-1-E8
Kink Conform to IEC 794-1-E10
Cable bend Conform to IEC 794-1-E11
Vibration Conform to IEC 794-1
Water penetration Conform to IEC 794-1-F5B
Abrasion Conform to IEC 794-1-E2
Temperature cycling test Conform to IEC 794-1-F1
Dielectric strength of outer jacket Conform to ITU-T Rec.K25

Characteristics:

◆ Good mechanical and temperature performance.
◆ High strength loose tube that is hydrolysis resistant.
◆ Special tube filling compound ensure a critical protection of fiber.
◆ High tensile strength of stranded wires meet the requirement of self-supporting and reduce the installation cost.
◆ The following measures are taken to ensure the cable watertight:
➢ Steel wire used as the central strength member
➢ Loose tube filling compound
➢ 100% cable core filling
➢ PSP enhancing moisture-proof
➢ Water-blocking material

Application:

1. Adopted to outdoor distribution.
2. Suitable for aerial.
3. Long distance and local area network communication.

Figure 8 GYTC8S Self Supporting Fiber Optic Cable Armored 72 Core Fiber Optic Cables
