GYFTA Loose Stranding Tube Aluminum Polyethylene Sheathed Armored Optical Cable
GYFTA Loose Stranding Tube Aluminum Polyethylene Sheathed Armored Optical Cable
GYFTA Loose Stranding Tube Aluminum Polyethylene Sheathed Armored Optical Cable
GYFTA Loose Stranding Tube Aluminum Polyethylene Sheathed Armored Optical Cable
Specifications
Brand Name :
YT
Model Number :
YT
Certification :
ISO, SGS, ROHS
Place of Origin :
china shenzhen
MOQ :
10 pcs
Price :
Negotiation
Payment Terms :
XTransfer T/T, Western Union, PayPal
Supply Ability :
5000 pcs/Month
Delivery Time :
3-7days
Sheath Material: :
Steel-Polyethylene
Tube :
PBT Loose Tube
Outer Sheath :
HDPE
Armored :
Aluminum Strip
Installation :
Aerial, Duct
Description

Aluminum Polyethylene Sheathed Duct And Aerial Armored Fiber Optic Cable Loose Stranding Tube

Quick Description

outdoor armored optical cable is suitable for aerial and duct installation where area with high incidence of lighting or exposure to hign voltage. Tubes of fiber GYFTA cable contain optical single-mode or multimode fibers color coded as per color coding scheme

Structure:

  • Optical fiber
  • Full-filled jelly
  • PBT Loose tube
  • Non-metallic central FRP strength members
  • Water blocking material
  • Aluminum Strip
  • HDPE sheath.

Technical Parameters

Fiber Count Tubes Fillers Cable Diameter Cable Weight kg/km Tensile Strength Crush Resistance
Bending Radius
Long/Short Term Static/Dynamic
mm Long/Short Term N N/100mm mm
2~6 1 5 10.6 88 400/1000 300/1000 10D/20D
8~12 2 4 10.6 88 400/1000 300/1000 10D/20D
14~18 3 3 10.6 88 400/1000 300/1000 10D/20D
20~24 4 2 10.6 88 400/1000 300/1000 10D/20D
26~30 5 1 10.6 88 400/1000 300/1000 10D/20D
32~36 6 0 10.6 88 400/1000 300/1000 10D/20D
2~6 1 6 11 97 600/1500 300/1000 10D/20D
8~12 2 5 11 97 600/1500 300/1000 10D/20D
14~18 3 4 11 97 600/1500 300/1000 10D/20D
20~24 4 3 11 97 600/1500 300/1000 10D/20D
26~30 5 2 11 97 600/1500 300/1000 10D/20D
32~36 6 1 11 97 600/1500 300/1000 10D/20D
38~42 7 0 11 97 600/1500 300/1000 10D/20D
44~48 4 2 12 113 600/1500 300/1000 10D/20D
50~60 5 1 12 113 600/1500 300/1000 10D/20D
62~72 6 0 12 113 600/1500 300/1000 10D/20D
2~6 1 7 12 120 1000/3000 300/1000 10D/20D
8~12 2 6 12 120 1000/3000 300/1000 10D/20D
14~18 3 5 12 120 1000/3000 300/1000 10D/20D
20~24 4 4 12 120 1000/3000 300/1000 10D/20D
26~30 5 3 12 120 1000/3000 300/1000 10D/20D
32~36 6 2 12 120 1000/3000 300/1000 10D/20D
38~42 7 1 12 120 1000/3000 300/1000 10D/20D
44~48 8 0 12 120 1000/3000 300/1000 10D/20D
50~60 5 2 13 137 1000/3000 300/1000 10D/20D
62~72 6 1 13 137 1000/3000 300/1000 10D/20D
74~84 7 0 13 137 1000/3000 300/1000 10D/20D
86~96 8 0 13.9 154 1000/3000 300/1000 10D/20D
98~108 9 1 15.3 185 1000/3000 300/1000 10D/20D
110~120 10 0 15.3 185 1000/3000 300/1000 10D/20

Our Serivces
Any question will be replied within 24 hours.
Professinal manufacture,Welcom to vist our company.
100% test before shipping.
OEM/ODM is avaliable(As required print logo and customized color).
Fast delivery time(2 days for samples,order 3~7 days for bulk production)
FAQ
Are you a trade company or a manufacturer?
We are an manufacturer specialized in Fiber Optic PLC splitter, Patch Cords,Adapter ,Fast connector and other Communication Products. OEM & ODM service are available.
What is your delivery date?
The delivery date is about 5-15 days after receipt of payment.
Can you send free samples?
Yes, free samples are available; you just need to pay the express fee. You can provide your a/c like DHL,
or you can call your courier to pick up from our office.
The cable marking can be as required to printing?
Yes,You have only to give us your marking.
