Outdoor Single/Multi Mode Fiber Optic Cable, GYTS with FRP, LSZH
Outdoor Single/Multi Mode Fiber Optic Cable, GYTS with FRP, LSZH
Outdoor Single/Multi Mode Fiber Optic Cable, GYTS with FRP, LSZH
Outdoor Single/Multi Mode Fiber Optic Cable, GYTS with FRP, LSZH
Outdoor Single/Multi Mode Fiber Optic Cable, GYTS with FRP, LSZH
Outdoor Single/Multi Mode Fiber Optic Cable, GYTS with FRP, LSZH
Outdoor Single/Multi Mode Fiber Optic Cable, GYTS with FRP, LSZH
Outdoor Single/Multi Mode Fiber Optic Cable, GYTS with FRP, LSZH
Outdoor Single/Multi Mode Fiber Optic Cable, GYTS with FRP, LSZH
Outdoor Single/Multi Mode Fiber Optic Cable, GYTS with FRP, LSZH
Outdoor Single/Multi Mode Fiber Optic Cable, GYTS with FRP, LSZH
Outdoor Single/Multi Mode Fiber Optic Cable, GYTS with FRP, LSZH
Specifications
Brand Name :
JUNPU
Model Number :
GYTS
Certification :
ROHS, CE, CCC
Place of Origin :
China
Payment Terms :
T/T
Supply Ability :
30000 Kilometer/Kilometers per Week anti-rodent 6 core optical fiber cable GYTS
Delivery Time :
1 ~ 10 Working days based on the quantity
Packaging Details :
wooden reel of anti-rodent 6 core optical fiber cable GYTS
Application :
Telecommunication,outdoor aerial,FTTH FTTB FTTX Network,Aerial/Duct,Municipalities/Co-ops/Utilities/Telco/Broadband/Enterprise
Fiber type :
G652D,OM3,G657A2,50/125,62.5/125
Number of conductors :
≥ 10
Fiber count :
4 ~ 192 Core
Jacket material :
PE,LSZH
Product Name :
GYTS 48 Core Armored Fiber Optic Cable Outdoor
Laying method :
aerial and pipeline laying method
Package :
2km/roll
Description

Outdoor Single/Multi Mode Fiber Optic Cable, GYTS With FRP, LSZH​


Decsripttion

  • GYTS The fibers,250μmm,are position in a loose tube made of a high modulus plastic.The tube are filled with a water resistant filling compound.A steel wire,sometimes sheathed with ployethylene(PE) for cable with high fiber count,locates in the center of core as a metallic strength member.
  • Tubes (and fillers) are stranded around the strength member into a compact and circular cable core.The PSP is longitudinally applied over the cable core,which is filled with filling compound to protect it from water ingress,the cable is completed with a PE sheath.

Outdoor Single/Multi Mode Fiber Optic Cable, GYTS with FRP, LSZH

Features

  • Steel wire strength filler protect tube fiber.steel tape armored.
  • Good ultra violet radiation resistant property.
  • Good moisture-resistance.

Application

  • Mainly adopted to direct buried, duct and cable trench.

Optical Characteristics

No.

Characteristics

Parameter value

1

Tensile Strength

Short Term

1000N

Long Term

500N

2

Crush Resistance Strength (N/100mm)

Short Term

1000N

Long Term

300N

3

Min. Bending Radius (mm)

Dynamic

20D

Static

10D

4

Temperature Range

-40~+60°C

Outdoor Single/Multi Mode Fiber Optic Cable, GYTS with FRP, LSZH
Package
Outdoor Single/Multi Mode Fiber Optic Cable, GYTS with FRP, LSZH
Outdoor Single/Multi Mode Fiber Optic Cable, GYTS with FRP, LSZH
We sincerely invite you to send us inquiry for further details.
Junpu Cares About Every Single Details Of The Product For You !
