1，2, 4 core Outdoor Fiber Optic Cable, fiber optic cable Blue/blue green
1，2, 4 core Outdoor Fiber Optic Cable, fiber optic cable Blue/blue green
1，2, 4 core Outdoor Fiber Optic Cable, fiber optic cable Blue/blue green
1，2, 4 core Outdoor Fiber Optic Cable, fiber optic cable Blue/blue green
1，2, 4 core Outdoor Fiber Optic Cable, fiber optic cable Blue/blue green
1，2, 4 core Outdoor Fiber Optic Cable, fiber optic cable Blue/blue green
1，2, 4 core Outdoor Fiber Optic Cable, fiber optic cable Blue/blue green
1，2, 4 core Outdoor Fiber Optic Cable, fiber optic cable Blue/blue green
1，2, 4 core Outdoor Fiber Optic Cable, fiber optic cable Blue/blue green
1，2, 4 core Outdoor Fiber Optic Cable, fiber optic cable Blue/blue green
Specifications
Brand Name :
JUNPU
Model Number :
GYXTZW
Certification :
ROHS, CE, CCC
Place of Origin :
China
Payment Terms :
T/T
Supply Ability :
1000 Kilometer/Kilometers per Month Junpu Outdoor F8 8 Core Singlemode G.652D Fiber Optic Cable
Delivery Time :
1 ~ 10 Working days based on the quantity
Packaging Details :
Plastic/ Carton/wooden drum/Customized
Application :
Aerial, Duct
Fiber type :
Single Mode G652D
Number of conductors :
≥ 10
Fiber count :
1 2 4 Core
OEM :
Acceptable
Product Name :
GYXTZW Outdoor F8 8 Core Singlemode G.652D Fiber Optic Cable
Strength member :
steel wire
Package :
1km - 6km/roll
Jacket Material :
PE Outer Sheath
Description

1,2, 4 Core Outdoor Fiber Optic Cable, Fiber Optic Cable Blue/Blue Green

Characteristics:

  • Good mechanical and temperature performance.
  • PVC outer sheath and PE inner sheath make cable have nice moisture resistance performance.
  • Crush resistance and flexibility.
  • Small cable diameter,light cable weight,easily to install.
  • We can also provide OEM service,and the packing as customer’s requirement.

G.652 G.655 50/125μm 62.5/125μm



Attenuation(+20℃)		 @850nm ≤3.0dB/km ≤3.3dB/km
@1300nm ≤1.0dB/km ≤1.0dB/km
@1310nm ≤0.40dB/km
@1550nm ≤0.22dB/km ≤0.23dB/km

Bandwidth(Class A)		 @850nm ≥500MHz·km ≥200MHz·km
@1300nm ≥1000MHz·km ≥600MHz·km
Numerical Aperture 0.200±0.015NA 0.275±0.015NA
Cable cut-off wavelength ≤1260nm ≤1450nm

1，2, 4 core Outdoor Fiber Optic Cable, fiber optic cable Blue/blue green

Application

  • Adopted to Outdoor Aerial, Duct installation

1，2, 4 core Outdoor Fiber Optic Cable, fiber optic cable Blue/blue green
Package
1，2, 4 core Outdoor Fiber Optic Cable, fiber optic cable Blue/blue green
1，2, 4 core Outdoor Fiber Optic Cable, fiber optic cable Blue/blue green
We sincerely invite you to send us inquiry for further details.
Junpu Cares About Every Single Details Of The Product For You !
