24 Core GYFTA53 Outdoor Fiber Optic Cable 1km Per Price Armoured ROHS
24 Core GYFTA53 Outdoor Fiber Optic Cable 1km Per Price Armoured ROHS
Specifications
Brand Name :
JUNPU
Model Number :
Outdoor 24 Core GYFTA53 Fiber Optical Cable
Certification :
ROHS, CE, CCC
Place of Origin :
China
Payment Terms :
T/T
Supply Ability :
1000 Kilometer/Kilometers per Week
Delivery Time :
1 ~ 10 Working days based on the quantity
Packaging Details :
2KM/Wooden Drum
Application :
Aerial, Duct, Direct Buried
Fiber type :
G652D,OM3,G657A2,50/125,62.5/125
Number of conductors :
≥ 10
Fiber count :
2 - 144 Core
Jacket material :
PE,LSZH
Product Name :
Outdoor 24 Core GYFTA53 Fiber Optical Cable
Strength member :
FRP Strength Member
Package :
2km/roll
loose tube :
2-12 loose tube
Description

Outdoor 24 Core GYFTA53 Fiber Optical Cable 1km Price Armoured Fiber Optic Cable


Decsripttion

  • GYFTA53 The fibers, 250µm, are positioned in a loose tube made of a high modulus plastic. The tubes are filled with a water-resistant filling compound. A Fiber Reinforced Plastic (FRP) locates in the center of core as a non-metallic strength member. The tubes (and fillers) are stranded around the strength member into a compact and circular core. After an Aluminum Polyethylene Laminate (APL) moisture barrier is applied around the cable core, the cable is completed with a PE sheath.

24 Core GYFTA53 Outdoor Fiber Optic Cable 1km Per Price Armoured ROHS

Features

  • Good mechanical and temperature performance
  • High strength loose tube that is hydrolysis resistant
  • Special tube filling compound ensure a critical protection of fiber
  • Specially designed compact structure is good at preventing loose tubes from shrinking
  • PE sheath protects cable from ultraviolet radiation
  • The following measures are taken to ensure the cable watertight:
  • Single Fiber Reinforced Plastic as the central strength member
  • Loose tube filling compound
  • 100% cable core filling
  • APL moisture barrier

24 Core GYFTA53 Outdoor Fiber Optic Cable 1km Per Price Armoured ROHS

Application

  • Aerial, Duct, Direct Buried.

Optical Characteristics

Fiber count
Available cable diameter (mm)
Cable weight (kg/km)
Tensile strength
long/short term(N)
Crush resistance
long/short term
(N/100mm)
2-36
11.4
108
500/1000
300/1000
2-72
12.8
134
600/1500
300/1000
2-48
12.8
140
1000/3000
300/1000
50-96
14.8
176
1000/3000
300/1000
98-120
17.1
226
1000/3000
300/1000
122-144
19.2
279
1000/3000
300/1000
24 Core GYFTA53 Outdoor Fiber Optic Cable 1km Per Price Armoured ROHS
Package
24 Core GYFTA53 Outdoor Fiber Optic Cable 1km Per Price Armoured ROHS
24 Core GYFTA53 Outdoor Fiber Optic Cable 1km Per Price Armoured ROHS
We sincerely invite you to send us inquiry for further details.
Junpu Cares About Every Single Details Of The Product For You !
