40G Fiber Optic Patch Cord 8/12/24 Cores SM / MM / OM3 MPO Fiber Patch Cord
40G Fiber Optic Patch Cord 8/12/24 Cores SM / MM / OM3 MPO Fiber Patch Cord
40G Fiber Optic Patch Cord 8/12/24 Cores SM / MM / OM3 MPO Fiber Patch Cord
40G Fiber Optic Patch Cord 8/12/24 Cores SM / MM / OM3 MPO Fiber Patch Cord
Specifications
Brand Name :
JUNPU
Model Number :
mpo patch cord
Certification :
ROHS CE CCC
Place of Origin :
China
MOQ :
1 Piece
Price :
Negotiation
Payment Terms :
T/T, Western Union, Credit Card Via Alibaba
Delivery Time :
1 ~ 10 Working days based on quantity
Packaging Details :
Standard Strong Carton Box
Product Name :
8/12/24 Cores SM/MM/OM3 MPO Fiber Patch Cord
Connector :
SC, LC,FC
Fiber Mode :
Simplex and Duplex, G652D, G655, anything, SM or MM
Length :
1m, 2m, 3m, 5m As Your Customeried
Jacket :
PVC/LSZH
Cable OD :
3.0mm, 0.9mm, 2.0mm
Connector type :
PC/UPC/APC,SC/FC/LC/ST
Application :
FTTH FTTB FTTX Network
Description

40G Fiber Optic Equipment 8/12/24 Cores SM/MM/OM3 MPO Fiber Patch Cord

FAQ:

Q1: What is your main products?
A: Fiber optic cable, patch cord, adapter, pigtail, connector, joint closure and so on.

Q2: What is your delivery time?
A: Generally, it will take 7-15 Working Days.The specific delivery time depends on the items and quantity of your order.

Q3: Can you offer Free Pre-Sales Consulting or Free Sample?
A: Yes. Evertop offer 12 hours quick pre-sales response and free consulting. Any kind of technical support are available for our customers. Free Samples are available, for your evaluation, if you are interested
Q4: How can I pay for order?
A: We accept T/T, L/C, western union.

Applications:

  • FTTH FTTB FTTX Network,
  • FTTA FTTH BBU RRU RRH LTE &
  • Base station,
  • For ODF internal link,
  • For room equipment internal link,
  • FTTH/Test equipments/TV/LAN/Telecommunication equipments

Specification:

tems Single mode Multimode
PC UPC APC 62.5/125 50/125 50/125 10G
Insertion Loss <0.2dB <0.3dB
Return Loss ≥45dB ≥50dB ≥60dB ≥35dB
Durability <0.1dB typical change,
500 matings
Operating Temperature -40 to +75°C -40 to +75°C
Ferrule Hole Sizes 125.0+1/-0um, Conentricity:≤1um 125um,Conectricity:1≤3um
125.3+1/-0um, Conentricity:≤1um 127um,Conectricity:1≤3um
125.5+1/-0um, Conentricity:≤1um 128um,Conectricity:1≤3um
126.0+1/-0um, Conentricity:≤1um

Connector Type Performance Level
Standard Elite
Connector Mode Endface IL(dB) RL(dB) IL(dB) RL(dB)
LC/SC/FC/ST SM PC ≤0.2 ≥50 ≤0.15 ≥50
UPC ≤0.2 ≥55 ≤0.15 ≥55
APC ≤0.2 ≥60 ≤0.15 ≥60
MM PC ≤0.2 ≥35 ≤0.15 ≥35
MPO/MTP SM APC ≤0.7 ≥60 ≤0.35 ≥60
MM PC ≤0.5 ≥20 ≤0.35 ≥20
MTRJ SM PC ≤0.5 ≥50 / /
MM PC ≤0.5 ≥35 / /

40G Fiber Optic Patch Cord 8/12/24 Cores SM / MM / OM3 MPO Fiber Patch Cord40G Fiber Optic Patch Cord 8/12/24 Cores SM / MM / OM3 MPO Fiber Patch Cord40G Fiber Optic Patch Cord 8/12/24 Cores SM / MM / OM3 MPO Fiber Patch Cord40G Fiber Optic Patch Cord 8/12/24 Cores SM / MM / OM3 MPO Fiber Patch Cord

Other Patch Cord Series:

40G Fiber Optic Patch Cord 8/12/24 Cores SM / MM / OM3 MPO Fiber Patch Cord
