Specifications
Brand Name :
GAPHO
Model Number :
1×8 rack-mounted optical switch
Place of Origin :
China
MOQ :
50
Price :
negotiate
Payment Terms :
T/T
Supply Ability :
10000
Delivery Time :
7-10 day
Packaging Details :
Carton
Monitoring Port :
RJ45, RS232
Product Name :
1×8 rack-mounted optical switch
Insertion Loss1,2 :
Typ:1 0 Max:1.2
Wavelength Range :
850±40 / 1300±40 ，1260-1650
Test Wavelength :
850 /1300 1310/1550
Return Loss1,2 :
SM≥45 MM≥ 30
Chassis Type :
1U L482.6xW200xH44
Relative Humidity :
5%-95%
Switching Time :
≤10ms(sequence switch time of adjacent channel)
Description

1X8&1x32 Rack mount Optical Switch,FITL/Automatic Measurement with RS232 Control and RJ45 Ethernet Remote Management

Description:

1×8 rack-mounted optical switch is a kind of functional device,with the ability of controlling and switching optical route. It can be manually selected from front panel or controlled via RS232 port, Ethernet port and auto-scanned on certain frequency. In optical fiber transmission system, it is used for multi-channel fiber monitoring, multi light source/ detector selection, and optical fiber path protection etc. Besides, it is also used in optical fiber test system for optical fiber and its component test, outdoor cable test and multi-spot optical sensors monitoring system.

Features:

  • Low insertion loss, Fast switching
  • SerialNet, High Reliability, High Stability
  • LED display panel. Visual display, Convenient operation
  • Transparent transmission signal. High stability and reliability
  • Channel and time interval of automatic scanning can be set up
  • RS232 Control and RJ45 Ethernet Remote Management

Application:

  • FITL
  • Cable Monitoring and Maintaining system
  • Automatic Measurement
  • Optical Network Remote Monitoring

Specifications:

Parameters Unit SUN-FSW-1*N-1U (SUN-FSW-1*N-1U (NS8)
NS8)
Insertion Loss1,2 dB Typ:1 0 Max:1.2
Wavelength Range nm 850±40 / 1300±40 1260-1650
Test Wavelength nm 850 /1300 1310/1550
Return Loss1,2 dB SM≥45 MM≥ 30
Crosstalk 1 dB ≥55
PDL dB ≤0.1
WDL dB ≤0.25
Repeatability dB ≤ ±0.05
Durability ≥10 Million
Optical Power mW ≤500
Switching Time ms ≤10 (sequence switch time of adjacent channel)
Operati ng r -60
Storage Temperature r -120
Relative Humidity % 5-95
Monitoring Port RJ45, RS232
Power Supply V AC: 100-240V (50/60Hz ) or DC: 36〜72V
Chassis Type mm 1U L482.6xW200xH44

Ordering Information:

N A B C D E
Channel Fiber Type Test Wavelength Power Supply Mode Connector Chassis Type
≤8

SM: SM, 9/125 M5: MM, 50/125

M6: MM, 62.5/125

X: Others

850: 850nm 1310:1310nm 1550:1550nm 1310/1550:1310/15 50nm

X:Others

AC: 100-240V

DC: 36-72V

AC/ DC: 100-240V/ 36-72V

AC/AC: Dual 100-240V

DC/DC: Dual 36*72V

X: Others

 FP: FC/PC FA: FC/APC SP: SC/PC SA: SC/APC X: Others 1U: L482.6*W200 xH44

Optical Route:

FITL Rack Mount 1x32 Fiber Optical Switch With RJ45 Ethernet Remote Management

Panel to Show:

FITL Rack Mount 1x32 Fiber Optical Switch With RJ45 Ethernet Remote Management

Power: Master switch of power supply
RJ45:Communications network management interface ;
RS-232: Rs- serial interface ; RS232 serial communication interface;
LCD:Devices that display information directly;
▲: Key to move up; ▼: Key to move down;
Enter: Key to determine;
Esc: Key to cancel;
com,1~8:Fiber interface;

FITL Rack Mount 1x32 Fiber Optical Switch With RJ45 Ethernet Remote ManagementFITL Rack Mount 1x32 Fiber Optical Switch With RJ45 Ethernet Remote ManagementFITL Rack Mount 1x32 Fiber Optical Switch With RJ45 Ethernet Remote ManagementFITL Rack Mount 1x32 Fiber Optical Switch With RJ45 Ethernet Remote ManagementFITL Rack Mount 1x32 Fiber Optical Switch With RJ45 Ethernet Remote Management
