Mini 1x4 1x8 Fiber Optical Switch 1310nm Latching / Non Latching
Mini 1x4 1x8 Fiber Optical Switch 1310nm Latching / Non Latching
Mini 1x4 1x8 Fiber Optical Switch 1310nm Latching / Non Latching
Mini 1x4 1x8 Fiber Optical Switch 1310nm Latching / Non Latching
Specifications
Brand Name :
GAPHO
Model Number :
mini 1x4 Fiber optic switch
Place of Origin :
China
MOQ :
50
Price :
negotiate
Payment Terms :
T/T, T/T, D/P, D/A, L/C, MoneyGram
Supply Ability :
10000
Delivery Time :
7-10 day
Packaging Details :
Carton,pearl cotton,bubble bag,plastic bag
Operating Wavelength (nm) :
850&1310±40
Insertion Loss (dB)r :
≤1.0
Switching Speed (ms) :
≤10
Drive Voltage (V) :
5
Power Handing (mW) :
500
Fiber Type :
SMF-28
Description

Mini 1x4A. mini-1X4 Optical Switch.pptx 1x8 A Mini 1x8.pptxoptical switch 1310 nm Latching or Non-Latching fiber length customer Specify

  • Unmatched Low Cost
  • Low Insertion Loss
  • High Channel Isolation
  • Highly Stable and Reliable
  • Epoxy-Free Optical path
  • Latching or Non-Latching

◇ Application:

  • Optical Netrwork Protection/Restoration
  • Optical Signal Routing
  • Configurable Optical Add/Drop
  • Transmitter and Receiver Protection
  • Network Test Systems
  • Instrumentation

specification

Parameter Specification
Operating Wavelength (nm) 850&1310±40 1260~1650
Insertion Loss (dB) ≤1.0 ≤1.0
WDL (dB) ≤0.25 ≤0.30
PDL (dB) ≤0.1
Channel Cross Talk (dB) ≥40 ≥55
Repeatability (dB) ±0.02
Return loss (dB) ≥35 ≥55
Switching Speed (ms) ≤10
Drive Voltage (V) 5
Power Handing (mW) 500
Durability (Cycles) 10 Million
Switching Type Latching or Non-latching
Operating Temperature (℃) -5～70
Storage Temperature (℃) -40～85
Fiber Type SMF-28
Fiber Length (m) Customer Specify
Dimension (L×W×H) (mm) 35×23×10

◇pins

latching type

Mini 1x4 1x8 Fiber Optical Switch 1310nm Latching / Non Latching

Non-latching type

Mini 1x4 1x8 Fiber Optical Switch 1310nm Latching / Non Latching

◇dimensions Mini 1x4

Mini 1x4 1x8 Fiber Optical Switch 1310nm Latching / Non Latching

mini1x8

Mini 1x4 1x8 Fiber Optical Switch 1310nm Latching / Non Latching

◇Ordering Information:MSW－4x4－A－B－C－D－E-G

A B C D E F G
Mode Wavelength Voltage Control Model Fiber Diameter Fiber Length Connector

SM:9/125um

M5: 50/125um

M6: 62.5/125um

85: 850nm

13: 1310nm

14: 1490nm

15: 1550nm

162: 1625nm

165: 1650nm

13/15:1310/1550nm

3: 3V

5: 5V

L: Latching

N:Non-Latching

25:250um

90:900um

20:2.0mm

30: 3.0mm

05:0.5m

10:1.0m

15:1.5m

OO:None

FP: FC/PC

FA: FC/APC

SP: SC/PC

SA: SC/APC

LP: LC/PC

LA: LC/APC

Mini 1x4 1x8 Fiber Optical Switch 1310nm Latching / Non Latching

Mini 1x4 1x8 Fiber Optical Switch 1310nm Latching / Non Latching

other products

Mini 1x4 1x8 Fiber Optical Switch 1310nm Latching / Non Latching

Mini 1x4 1x8 Fiber Optical Switch 1310nm Latching / Non Latching

Mini 1x4 1x8 Fiber Optical Switch 1310nm Latching / Non Latching

Mini 1x4 1x8 Fiber Optical Switch 1310nm Latching / Non Latching

FAQ

Q:Can you design and customize production according to my requirements

A:Yes, you can tell us your requirements and ideas, we can design drawings, or provide samples, 2D floor plans or 3D drawings (support proe, solidwork, core, Auto CAD, DXF, DWG, step file formats).

Q: Are you trading company or manufacturer ?

A: We are factory.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q:When our company be established?

A: We started from year 2013

Q: Can you provide samples for customers?

A: Yes, but the shipping will be charged on the customer's account.

Q:Do you offer OEM services?

A: We accept OEM, ODM. Cable sizes and materials can be customized.
