Specifications
Brand Name :
GAPHO
Model Number :
FWDM
Place of Origin :
China
MOQ :
50
Price :
negotiate
Payment Terms :
T/T, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10000
Delivery Time :
7-10 day
Packaging Details :
Carton,pearl cotton,bubble bag,plastic bag
Package Dimension (mm) :
80 x 60 x 10
Storage Temperature (°C) :
-40 ~ +85
Operating Temperature (°C) :
0 ~ +70
Power Handling (mW) :
300
Return Loss (dB) :
≥ 45
Directivity (dB) :
≥50
Express Channel Isolation (dB) :
> 25
Insertion Loss Temperature Sensitivity(dB/°C ) :
< 0.003
Description

100Ghz Optical Add/drop Module(OADM) 1530.33 ~ 1560.61 (21~ 59 ITU grid)A 100Ghz Optical Adddrop Module(OADM).docx

Features

  • Low Insertion Loss
  • High Channel Isolation
  • High stability and reliability

Application

  • DWDM Network
  • Wavelength Routing
  • Fiber Optical Amplifier
  • CATV Fiber optic System

specifications

Type Parameter

 1ch 2ch
Channel Wavelength (nm) 1530.33 ~ 1560.61 (21~ 59 ITU grid)
Center Wavelength Accuracy (nm) ± 0.05
Minimum Channel Spacing (GHz) 100
Channel Passband (@-0.5dB bandwidth)(nm) > 0.22

Insertion Loss (dB)

 Add / Drop Ch1 ≤1.2 ≤1.2
Add / Drop Ch 2 - ≤1.5
Express Ch. ≤1.0 ≤1.4
Add / Drop Channel Ripple (dB) ≤0.3

Isolation (dB)

Demux

 Adjacent Ch. ≥ 25
Non-adjacent Ch. ≥40

Mux

 Adjacent Ch. N/A
Non-adjacent Ch. N/A
Express Channel Isolation (dB) > 25
Insertion Loss Temperature Sensitivity(dB/°C ) < 0.003
Wavelength Temperature Shifting (nm/ C ) < 0.002
Polarization Dependent Loss (dB) < 0.10
Polarization Mode Dispersion (ps) < 0.1
Directivity (dB) ≥50
Return Loss (dB) ≥ 45
Power Handling (mW) 300
Operating Temperature (°C) 0 ~ +70
Storage Temperature (°C) -40 ~ +85
Package Dimension (mm) 80 x 60 x 10

Ordering information

OADM Spacing Channel Type

ITU

Channel

 Pigtail Type Fiber Type Lengt h Connector
1=100Ghz 1=1ch 2=2ch

21=21ch

22=22ch

…… 60=60ch

 900=900um loose tube 2000=2mm loose tube 3000=3mm loose tube 1=SMF-28e

1= 1m

X=Specify

 NE=None FA=FC/APC FC=FC/UPC SA=SC/APC SC=SC/UPC LC=LC/UPC LA=LC/APC
