TFT Color LCD Display Fiber Optic Splicer , FONGKO Fiber Optic Splicing Machine
TFT Color LCD Display Fiber Optic Splicer , FONGKO Fiber Optic Splicing Machine
TFT Color LCD Display Fiber Optic Splicer , FONGKO Fiber Optic Splicing Machine
TFT Color LCD Display Fiber Optic Splicer , FONGKO Fiber Optic Splicing Machine
TFT Color LCD Display Fiber Optic Splicer , FONGKO Fiber Optic Splicing Machine
TFT Color LCD Display Fiber Optic Splicer , FONGKO Fiber Optic Splicing Machine
TFT Color LCD Display Fiber Optic Splicer , FONGKO Fiber Optic Splicing Machine
TFT Color LCD Display Fiber Optic Splicer , FONGKO Fiber Optic Splicing Machine
TFT Color LCD Display Fiber Optic Splicer , FONGKO Fiber Optic Splicing Machine
TFT Color LCD Display Fiber Optic Splicer , FONGKO Fiber Optic Splicing Machine
TFT Color LCD Display Fiber Optic Splicer , FONGKO Fiber Optic Splicing Machine
TFT Color LCD Display Fiber Optic Splicer , FONGKO Fiber Optic Splicing Machine
Specifications
Brand Name :
Fongko
Model Number :
FKEQU-122
Certification :
CE
Place of Origin :
Shenzhen
MOQ :
1 set
Price :
Negotiatable
Payment Terms :
L/C, T/T
Delivery Time :
3 days
Product name :
Fiber Optic Splicing Machine
Applicable cable :
Optical Fiber cable splicing
Language :
(Chinese/English) 2 Languages
Application :
construction, inspection, maintenance of fiber cable
Splicing loss :
0. 02dB (SM) , 0. 01dB (MM) 0. 04dB (DS/NZDS)
Display :
5.0 inches TFT color LCD display Reversible, convenient for bi-directional operation
Description

Product overview

Fibre Splicing Machine is a special design for the installation, operation and maintenance of optical fiber specially design a precision, durable, convenient optical fiber construction instrument. Fiber Fusion Splicer Machine widely used in the construction, inspection, maintenance of fiber cable.
Optical fiber clamp Multi-function clamp for bare fiber, tail fiber, jumpers,leather line; changing clamp applicable for sC and otherconnectors for a
variety of FTTx optical fiber and cable.
Amplification factor 300 times (x axis or Y axis)
Heat shrink bush 60mm,40mm and a series of miniature bush
Display 5.0 inches TFT color LCD display Reversible, convenient for bi-directional operation
External interface USB interface,convenient for data download and software upgrade
Splicing mode 17 groups of operation modes
Heating mode 9 groups of operation modes
Splicing loss storage 5000 latest splicing results are stored in the built-in storage.
Built in battery Supports continuous splicing and heating for not less than 200 times
Power supply The built-in lithium battery 11.8V supplies the power,charging time≤3.5h;External adapter,input AC100-240V50/60HZ,output
DC13.5V/4.81A
Power saving 15% of the power of the lithium battery can be savedin a typical environment.
Working environment Temperature:-10~+50℃,Humidity :
Outer dimension 205mm (long) x140mm (wide) x123mm (high)
Lighting Convenient for optical fiber installation in the evening
Weight 1434g (excl. battery) 1906g (incl. battery)
