Cerium Oxide 0.5um Square Diamond Lapping Paper 127mm Fiber Optic Polishing Film
Cerium Oxide 0.5um Square Diamond Lapping Paper 127mm Fiber Optic Polishing Film
Cerium Oxide 0.5um Square Diamond Lapping Paper 127mm Fiber Optic Polishing Film
Cerium Oxide 0.5um Square Diamond Lapping Paper 127mm Fiber Optic Polishing Film
Cerium Oxide 0.5um Square Diamond Lapping Paper 127mm Fiber Optic Polishing Film
Cerium Oxide 0.5um Square Diamond Lapping Paper 127mm Fiber Optic Polishing Film
Specifications
Brand Name :
CLX
Model Number :
CO-0.5um
Certification :
ROHS/ISO9001
Place of Origin :
Guangdong,China
MOQ :
100 Piece
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
200000/month
Delivery Time :
5-8 work days
Packaging Details :
100 Piece/Package 0.5Kg,22X22X9 cm
Product name :
Fiber Optic Polishing Films
Type :
Fiber optic polishing consumables
Dimensions :
127mm
Color :
brown
Material :
Cerium Oxide
Application :
Connectors polishing
Weight :
0.002kg
Apllication :
Fiber Optic Connector, Ceramics Ferrule
Description

Cerium Oxide 0.5um Square Lapping Polishing Film 127mm Fiber Optic Polishing Films

Description
Fiber optic polishing film is coated with precisely graded minerals (such as diamond, aluminum oxide, silicon carbide, silicon oxide, cerium oxide and so on) on the high strength polyester backing to provide a uniform, consistent finish. Available in 0.01-45 μm grades, with or without PSA (Pressure Sensitive Adhesive) backing.

Specification

ModelCO-0.5UM
Place of OriginChina
Standard SizeΦ127mm (5inch)
MaterialCerium Oxide
Article Grade0.5UM
ColorBrown
Recommended Polishing MediumWater/Oil
ApllicationFiber Optic Connector, Ceramics Ferrule
Package100pcs / set
Storage ConditionTemp: 10~30℃ Humid: 30~70%

Order Options

Part NumberMaterialApplicationPacking
GA5D-30umSilicon CarbideEpoxy Removal20pcs/pack
DR5D-9umDiamondCoarse Polishing20pcs/pack
DG5D-5umDiamondMedium Polishing20pcs/pack
DH5D-3umDiamondMedium Polishing20pcs/pack
DI5D-1.5umDiamondFine Polishing20pcs/pack
DJ5D-1umDiamondFinal Polishing20pcs/pack
XF5D-0.02umSilicone DioxideUPC Final Polishing100pcs/pack
D30-30umDiamondAdhesive Removal50pcs/pack
D9-9umDiamondCoarse Polishing50pcs/pack
D5-5umDiamondMedium Polishing50pcs/pack
D3-3umDiamondMedium Polishing50pcs/pack
D1-1umDiamondFine Polishing50pcs/pack
ADS-127Silicone DioxideFinal Polishing100pcs/pack
SC-16umSilicon CarbideMedium Polishing50pcs/pack
SC-3umSilicon CarbideMedium Polishing50pcs/pack
SC-1umSilicon CarbideFine Polishing50pcs/pack
AA1-MFPSFlocked Film Without AbrasiveMPO Polishing50pcs/pack
CE1-MFPSFlocked Film Without AbrasiveMPO Polishing50pcs/pack
MFP610Flocked Film Without AbrasiveMPO Final Polishing50pcs/pack
Remark: (1) All polishing films could be manufactured according to custom design.
(2) If you could not find the polishing films you want, please feel free to contact us via email or phone.


Cerium Oxide 0.5um Square Diamond Lapping Paper 127mm Fiber Optic Polishing Film

Feature
1. Full stainess steel polishing plate, more reliable and stable.
2. Double motors with sufficient power.
3. High accuraty Machinary size, minimal plane tolerance.
4. Rotation speed and time adjustable with simple operation.
5. Excellent stability, five or ten years lifetime.

Cerium Oxide 0.5um Square Diamond Lapping Paper 127mm Fiber Optic Polishing Film
